Image Sensor:
1/2.8" Progressive Scan CMOS
Min. Illumination:
Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
Focus:
Fixed
Lens Type:
2.8/4/6/8 mm
FOV:
2.8 mm, horizontal FOV: 114°, vertical FOV: 62°, diagonal FOV: 135°,4 mm, horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102°,6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 62°,8 mm, horizontal FOV: 43°, vertical FOV: 23°, diagona
Aperture:
F2.0
Lens Mount:
M12
Aperture Type:
Fixed
IR Range:
Up to 30 m
Wavelength:
850nm
Max. Resolution:
1920 × 1080
Main Stream:
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub Stream:
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream:
50Hz: 25fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288),60Hz: 30fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 240)
Video Compression:
Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream supports
H.265:
Main stream supports
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression:
G722.1/G.711/G726/MP2L2/PCM/MP3
Audio Bit Rate:
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3)
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, WebSocket, WebSockets
User/Host:
Up to 32 users,3 levels: Administrator, Operator and User
Network Storage:
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local Service: Chrome 41.0+, Firefox 30.0+
Alarm Trigger:
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by alarm in (-S)
Target Cropping:
No
DNR:
3D DNR
Image Enhancement:
BLC/3D DNR/HLC
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
Audio:
1 input (line in/mic in), 1 output (line out), terminal block, mono sound
Alarm:
1 input, 1 output (max. 12 VDC, 30 mA), terminal block
Video Output:
No
On-Board Storage:
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, intrusion detection, face detection
Face Detection:
Yes
Linkage Method:
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output , Email
Firmware Version:
5.6.3
Web Client Language:
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditiona
General Function:
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Startup And Operating Conditions:
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply:
12 VDC ± 25%, F 5.5 mm coaxial power plug,PoE (802.3af, class 3)
Power Consumption And Current:
12 VDC, 0.5 A, max. 6 W,PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 7.5 W
Camera Dimension:
Camera: F 111 × 82.4 mm (F 4.4" × 3.2"),Package: 134 × 134 × 108 mm (5.3" × 5.3" × 4.3")
Camera Weight:
Camera: Approx. 610 g (1.3 lb.),With Package: Approx. 820 g (1.8 lb.)
Protection:
IK10, IP67
