Image Sensor:
1/2.5" Progressive Scan CMOS
Min. Illumination:
Color: 0.008 lux @(F1.2, AGC ON), 0.011 lux @(F1.4, AGC ON), 0 lux with IR
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 360°
Focus:
Auto
Lens Type:
2.8 to 12 mm,Motorized
FOV:
Horizontal field of view: 114° to 32°;Vertical field of view: 59° to 18°;Diagonal field of view: 141° to 36.5°
Aperture:
F1.4
Lens Mount:
Φ14
IR Range:
Up to 30 m
Wavelength:
850nm
Max. Resolution:
2688 × 1520
Main Stream:
50Hz: 25fps (2688 × 1520, 2304 × 1296, 1920 × 1080);60Hz: 30fps (2688 × 1520, 2304 × 1296, 1920 × 1080)
Sub Stream:
50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240);60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
Third Stream:
50Hz: 25 fps (1280 × 720, 640 × 360, 352 × 288);60Hz: 30 fps (1280 × 720, 640 × 360, 352 × 240)
Video Compression:
Main stream: H.265/H.264,Sub stream: H.265/H.264/MJPEG,Third stream: H.265/H.264
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream supports
H.265:
Main stream supports
Scalable Video Coding (SVC:
Support H.264 and H.265 encoding
Region Of Interest (ROI:
Support 1 fixed region for main stream and sub stream
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8kHz/16kHz/32kHz/44.1kHZ/48kHz
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate:
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome
Protocols:
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
User/Host:
Up to 32 users,3 levels: Administrator, Operator and User
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network Storage:
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local Service: Chrome 41.0+, Firefox 30.0+
Alarm Trigger:
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error, Alarm input, Alarm output
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by Alarm In
DNR:
3D DNR
Image Enhancement:
BLC/3D DNR/HLC
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Audio:
1 input (line in, 3.5 mm), 1 output(3.5 mm), mono sound
Alarm:
1 input, 1 output (max. 12 VDC, 30 mA)
Video Output:
No
On-Board Storage:
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Smart Event:
Line crossing detection, intrusion detection, unattended baggage detection, object removal detection
Face Detection:
Yes
Exception Detection:
Scene change detection
Firmware Version:
V5.5.80
Web Client Language:
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditiona
General Function:
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Startup And Operating Conditions:
-30 ��C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply:
12 VDC ± 25%, PoE (802.3af),Terminal block for DC input
Power Consumption And Current:
12 VDC, 1 A, max. 11 W, PoE (802.3af, 36V to 57V), 0.4 A to 0.3 A, max. 12.5 W
Camera Dimension:
Φ 135.8 mm × 145.5 mm (Φ 5.35" × 5.73")
Camera Weight:
With Package: Approx. 1220 g (2.69 lb.),Camera: Approx. 1060 g (2.34 lb.)
Protection:
IK10,IP66
