Image Sensor:
1/1.8ʺ Progressive Scan CMOS
Min. Illumination:
Color: 0.007 Lux @ (F1.2, AGC ON); B/W: 0.0007 Lux @ (F1.2, AGC ON)
Shutter Speed:
1 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120 dB
Day & Night:
IR cut filter
Lens Mount:
CS mount
Auto-Iris:
P-iris
Max. Resolution:
3840 × 2160
Video Stream:
5 defined streams and up to 5 custom stream
Main Stream:
50Hz: 25fps (3840 × 2160, 3200 × 1800, 2560 × 1440, 1920 × 1080, 1280 × 720), 60Hz: 30fps (3840 × 2160, 3200 × 1800, 2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream:
50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Third Stream:
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream:
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream:
50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480)
Custom Stream:
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264 Sub stream/third stream/fourth stream/fifth stream/custom stream: H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream support
H.265:
Main stream support
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate:
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)
Simultaneous Live View:
Up to 20 channels
API:
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Smooth Streaming:
Yes
User/Host:
Up to 32 users. 3 user levels: administrator, operator and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTT
Network Storage:
microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR, Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 45+, Mozilla Firefox52+
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by Alarm In
Target Cropping:
Yes
Picture Overlay:
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format
Image Enhancement:
BLC, HLC, 3D DNR, Defog, EIS
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Audio:
1 input (line in), 1 output (line out), 2-core terminal block, mono sound
Alarm:
2 inputs, 2 outputs (max. 24 VDC/VAC, 1A max.)
Video Output:
1Vp-p composite output (75 Ω/CVBS), only for adjustment
On-Board Storage:
Built-in microSD/SDHC/SDXC slot, up to 256 GB
Hardware Reset:
Reset via reset button on camera body, web browser and client software
Communication Interface:
1 RJ45 10M/100M/1000M Ethernet port, 1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Power Output:
12 VDC, max. 200 mA
Interface Style:
Socket style interface
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, up to 4 lines configurable, Intrusion detection, up to 4 regions configurable, Region entrance detection, up to 4 regions configurable, Region exiting detection, up to 4 regions configurable, Unattended baggage detection, up
Premier Protection:
Line crossing, intrusion, region entrance, region exiting, Support alarm triggering by specified target types (human and vehicle), Filtering out false alarm caused by target types such as leaf, light, animal, and flag, etc.
Firmware Version:
V5.5.90
Web Client Language:
32 languages, English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Tradition
General Function:
Anti-flicker, 5 streams and up to 5 custom streams, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter
Startup And Operating Conditions:
-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
Power Supply:
12 VDC is recommended, 10 to 48 VDC; reverse polarity protection; 24 VAC is recommended, 15 to 36 VAC; PoE (802.3af, class 3)
Power Consumption And Current:
With extra load: 12 VDC, 1 A, max. 12 W; 24 VAC, 0.9 A, max. 12 W; PoE (802.3af, 36 V to 57 V), 0.1 A to 0.3 A, class 3, 12 W, Without extra load: 12 VDC, 0.8 A, max. 9.6 W; 24 VAC, 0.7 A, max. 9.6 W; PoE (802.3af, 36 V to 57 V), 0.1 A to 0.3 A, clas
Camera Dimension:
Camera: 142.6 × 69.8 × 68 mm (5.61" × 2.75" × 2.68"), Package: 315 × 140 × 140 mm (12.4" × 5.51" × 5.51")
Camera Weight:
-AP: approx. 730 g (1.61 lb.), 1020 g (2.25 lb.) with packageNon-AP: approx. 690 g (1.52 lb.), 975 g (2.15 lb.) with package
EMC:
47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015
Safety:
UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015
Environment:
2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006
