Image Sensor:
1/2.8" Progressive Scan CMOS
Max. Resolution:
2560 × 1440
Min. Illumination:
Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux @ (F1.5, AGC ON), 0 Lux with IR
Shutter Speed:
1/1 s to 1/30,000 s
Day & Night:
IR cut filter
Zoom:
4x optical, 16x digital
Slow Shutter:
Yes
Focal Length:
2.8 to 12 mm
FOV:
Horizontal FOV 96.796° to 31.68°, vertical FOV 51.16° to 17.798°, diagonal FOV 115.13° to 36.32°
Focus:
Auto, semi-auto, manual
Aperture:
Max. F1.5
Zoom Speed:
Approx. 2 s
Supplement Light Type:
IR
Supplement Light Range:
IR Distance: up to 20 m
Smart Supplement Light:
Yes
IR Wavelength:
850 nm
Movement Range (Pan:
0° to 355°
Movement Range (Tilt:
0° to 90°
Pan Speed:
Pan speed: configurable from 0.1° to 100°/s; preset speed: 100°/s
Tilt Speed:
Tilt speed: configurable from 0.1° to 100°/s, preset speed 100°/s
Proportional Pan:
Yes
Presets:
300
Preset Freezing:
Yes
Park Action:
Preset
3D Positioning:
Yes
PTZ Status Display:
Yes
Scheduled Task:
Preset, dome reboot, dome adjust
Power-Off Memory:
Yes
Main Stream:
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720); 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288); 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream:
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288); 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264;Sub-stream: H.265/H.264/MJPEG;Third stream: H.265/H.264/MJPEG
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main profile
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
8 fixed regions for each stream
Audio Compression:
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM/AAC
Audio Bit Rate:
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/16-64Kbps(AAC)
Audio Sampling Rate:
AAC: 16 kHz, 32 kHz, 48 kHz; MP2L2: 16 kHz, 32 kHz, 48 kHz; PCM: 8 kHz, 16 kHz, 32 kHz, 64 kHz
Environment Noise Filtering:
Yes
Protocols:
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Simultaneous Live View:
Up to 20 channels
API:
Open Network Video Interface (Version 18.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
User/Host:
Up to 32 users; 3 user levels: administrator, operator, and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, control timeout settings, security audit log, TLS 1.2, host
Network Storage:
NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Client:
iVMS-4200, HikCentral Pro, Hik-Connect
Web Browser:
IE 10-11, Chrome 57+, Firefox 52+, Safari 11+
Image Parameters Switch:
Yes
Image Settings:
Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Day/Night Switch:
Day, Night, Auto, Schedule
Wide Dynamic Range (WDR:
120 dB
SNR:
＞52dB
Defog:
Digital Defog
Image Enhancement:
BLC, HLC, 3D DNR
Privacy Mask:
24 programmable polygon privacy masks, mask color or mosaic configurable
Regional Focus:
Yes
Regional Exposure:
Yes
Ethernet Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
On-Board Storage:
Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
Built-In Microphone:
1 built-in microphone, picking up sounds in the radius up to 5 meters
Audio:
1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
Reset:
Yes
Power Output:
12 VDC, max. 60 mA
Basic Event:
Motion detection, video tampering alarm, exception
Smart Event:
Face detection, line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
Linkage:
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, and PTZ actions (such as preset)
Power:
12 VDC, Max. 9.2 W; PoE (802.3af)
Dimension:
Ø 130.7 mm ×101.7 mm (Ø 5.15" × 4.00")
Weight:
Approx. 530 g (1.17 lb.)
Operating Condition:
-20 °C to 60 °C (-4 °F to 140 °F). Humidity 90% or less (non-condensing)
General Function:
Mirror, password protection
Protection:
IP66 (IEC 60529-2013), IK10, TVS 4000V lightning protection, surge protection and voltage transient protection
