Model:
i.MX 8M Nano
Memory:
1024 MB RAM, 1024 MB Flash
Enclosure:
Re-entrant horn loudspeaker with compression driver
Max sound pressure level:
>121 dB
Frequency response:
280 Hz - 12.5 kHz
Coverage pattern:
70° horizontal by 100° vertical (at 2 kHz)
Audio input/output:
Built-in microphone (can be disabled mechanically) Built-in speaker
Built-in microphone specification:
50 Hz - 12 kHz
Digital signal processing:
Built-in and pre-configured
Amplifier description:
Built-in 7 W Class D amplifier
AXIS Audio Manager Edge:
Built in: – Content management for music and live/pre-recorded announcements. – Scheduling to decide when and where to play specific content. – Content prioritization to ensure urgent messages interrupt the schedule.
AXIS Audio Manager Pro:
For larger and more advanced systems. Sold separately. See separate datasheet for specifications.
AXIS Audio Manager Center:
AXIS Audio Manager Center is a cloud service for remote access and management of multi-site systems.
Audio streaming:
One-way/two-way with optional half-duplex echo cancellation. Mono.
Audio encoding:
AAC LC 8/16/32/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Axis µ-law 16 kHz, WAV, MP3 in mono/stereo from 64 kbps to 320 kbps. Constant and variable bit rate. Sampling rate from 8 kHz up to 48 kHz.
Network protocols:
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa, HTTP/2, TLSa, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4
Application Programming Interface:
Open API for software integration, including VAPIX®, metadata and AXIS Camera Application Platform (ACAP); specifications at axis.com/developer-community. ACAP includes Native SDK.
Video management systems:
Compatible with AXIS Companion, AXIS Camera Station, video management software from Axis’ Application Development Partners available at axis.com/vms
Intelligent audio:
Auto Speaker Test
Event conditions:
Audio: audio clip playing, speaker test result Device status: IP address blocked/removed, live stream active, network lost, new IP address, system ready Edge storage: recording ongoing, storage disruption, storage health issues detected
Event actions:
Audio: run automatic speaker test Audio clips: play, stop I/O: toggle I/O Light and siren: run, stop MQTT: publish Notification: HTTP, HTTPS, TCP and email Recordings: record audio SNMP trap messages: send message Status LED: flash
Built-in installation aids:
Test tone verification and identification
Functional monitoring:
Auto Speaker Test, Connection verification, Built-in system logging
Product markings:
CSA, UL/cUL, UKCA, CE, KC, EAC, VCCI, RCM
Supply chain:
TAA compliant
EMC:
EN 55035, EN 55032 Class B, EN 50121-4, EN 61000-6-1, EN 61000-6-2 Australia/New Zealand: RCM AS/NZS CISPR 32 Class B Canada: ICES-3(B)/NMB-3(B) Japan: VCCI Class B Korea: KS C 9835, KS C 9832 Class B USA: FCC Part 15 Subpart B Class B Railway
Safety:
CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3
Environment:
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, NEMA 250 Type 4X, MIL-STD-810G 509.5, MIL-STD-810H 509.7
Cybersecurity:
ETSI EN 303 645
Edge security:
Software: Signed firmware, brute force delay protection, digest authentication, password protection Hardware: Axis Edge Vault cybersecurity platform Secure element (CC EAL 6+), Axis device ID, secure keystore, secure boot
Network security:
IEEE 802.1X (EAP-TLS)a, IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE 802.1AR, HTTPS/HSTSa, TLS v1.2/v1.3a, Network Time Security (NTS), X.509 Certificate PKI, host-based firewall
Documentation:
AXIS OS Hardening Guide Axis Vulnerability Management Policy Axis Security Development Model AXIS OS Software Bill of Material (SBOM)
Casing:
IP66- and NEMA 4X-rated Aluminum back can and stainless steel bracket Color: white RAL 9010
Power:
Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3 Typical 2 W, max 12.95 W
Connectors:
Network: RJ45 10BASE-T/100BASE-TX PoE I/O: 4-pin 2.5 mm terminal block for 2x supervised configurable I/Os
Reliability:
Designed for 24/7 operation.
Operating conditions:
Temperature: -40 °C to 60 °C (-40 °F to 140 °F) Humidity: 10-100% RH (condensing)
Storage conditions:
Temperature: -40 °C to 65 °C (-40 °F to 149 °F) Humidity: 5–95% RH (non-condensing)
Dimensions:
For the overall product dimensions, see the dimension drawing in this datasheet.
Weight:
1.3 kg (2.9 lb.)
Box content:
Horn speaker, installation guide, terminal block connector, connector guard, cable gasket, ring terminal, owner authentication key
Optional accessories:
AXIS T91B47 Pole Mount, AXIS T91F67 Pole Mount, Cable Gland M20x1.5, RJ45, Cable Gland A M20, AXIS Power over Ethernet Midspans, T94R01B Corner Bracket, T94P01B Corner Bracket, T94S01P Conduit Back Box
Languages:
English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese
Warranty:
5-year warranty
Part numbers:
Available at axis.com/products/axis-c1310-e-mk-ii#part-numbers
Substance control:
PVC free in accordance with JEDEC/ECA Standard JS709 RoHS in accordance with EU RoHS Directive 2011/65/EU/ and EN 63000:2018 REACH in accordance with (EC) No 1907/2006. For SCIP UUID, see echa.europa.eu
Materials:
Screened for conflict minerals in accordance with OECD guidelines
Environmental responsibility:
Axis Communications is a signatory of the UN Global Compact, read more at unglobalcompact.org
