Enclosure:
One way enclosure with 4 inches broadband dynamic cone speaker
Max sound pressure level:
93 dB
Frequency response:
70 Hz - 16 kHz
Coverage pattern:
130° coaxial
Audio input/output:
Built-in microphone (can be disabled) External microphone, line in
Built-in microphone specification:
50 Hz - 20 kHz
Amplifier description:
Built-in 7 W Class D amplifier
Digital signal processing:
Built-in and pre-configured
AXIS Audio Manager Edge:
Built in: – Content management for music and live/pre-recorded announcements. – Scheduling to decide when and where to play specific content. – Content prioritization to ensure urgent messages interrupt the schedule.
AXIS Audio Manager Pro:
For larger and more advanced systems. Sold separately. See separate datasheet for specifications.
AXIS Audio Manager Center:
AXIS Audio Manager Center is a cloud service for remote access and management of multi-site systems.
Audio streaming:
One-way/two-way with optional half-duplex echo cancellation. Mono.
Audio encoding:
AAC LC 8/16/32/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Axis µ-law 16 kHz, WAV, MP3 in mono/stereo from 64 kbps to 320 kbps. Constant and variable bit rate. Sampling rate from 8 kHz up to 48 kHz.
Model:
i.MX 6SoloX
Memory:
512 MB RAM, 512 MB Flash
Network protocols:
IPv4/v6a, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, Secure syslog (RFC 3164/5424, UDP/TCP/T
Application Programming Interface:
Open API for software integration, including VAPIX®, One-click cloud connection, AXIS Camera Application Platform (ACAP).
VoIP:
Support for Session Initiation Protocol (SIP) for integration with Voice over IP (VoIP) systems. Peer to peer or integrated with SIP/PBX. Tested with: SIP client such as Cisco, Bria and Grandstream and PBX suppliers such as Cisco and Asterisk.
Intelligent audio:
Auto Speaker Test (verification via built-in microphone)
Event triggers:
Call, virtual inputs, external input, AXIS Camera Application Platform (ACAP)
Event actions:
Play audio clip, send SNMP trap, send Auto Speaker Test, status LED, File upload via HTTP, network share and email, Notification via email, HTTP, HTTPS and TCP, external output activation
Built-in installation aids:
Test tone verification and identification
EMC:
CISPR 24, CISPR 35, CISPR 32 Class B, EN 55024, EN 55035, EN 55032 Class B, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4, FCC Part 15 Subpart B Class B, ICES-3(B)/NMB-3(B), KC KN35, KC KN32 Class B, RCM AS/NZS CISPR 32 Class B, VCCI Class B
Safety:
CAN/CSA C22.2 No. 62368-1, IEC/EN 62368-1, KC-Mark, UL 62368-1
Environment:
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, EC 60068-2-27, IEC/EN 60529 IP4X
Cybersecurity:
ETSI EN 303 645
Edge security:
Software: Signed OS, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption Hardware
Network security:
IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, host-based firewall
Documentation:
AXIS OS Hardening Guide Axis Vulnerability Management Policy Axis Security Development Model AXIS OS Software Bill of Material (SBOM)
Casing:
IP40 Baffle: plastic Mesh: surface-treated steel plate Mesh color: white NCS S 1002-B Top cover: plastic Repaintable. For repainting instructions and impact on warranty, contact your Axis partner. Speaker mounting method: hook
Power:
Power over Ethernet (PoE), IEEE 802.3af/802.3af, Type 1 Class 3 (max 12.95 W)
Connectors:
RJ45 10BASE-T/100BASE-TX PoE I/O: 4-pin 2.5 mm terminal block for 2x supervised configurable I/Os
Storage:
Support for microSD/microSDHC/microSDXC card Max. size 64 GB For SD card recommendations see www.axis.com
Reliability:
Designed for 24/7 operation.
LED indicators:
Status LED, front-facing LED
Operating conditions:
Temperature: -30 °C to 50 °C (-22 °F to 122 °F) Humidity: 10–85% RH (condensing)
Dimensions:
Height: 150 mm (5.9 in), Ø 220 mm (8.7 in)
Weight:
2650 g (5.8 lbs)
Optional accessories:
AXIS TC1901 Wire Kit, AXIS Safety Wire 3M
Video management software:
AXIS Companion, AXIS Camera Station, video management software from Axis’ Application Development Partners available on axis.com/techsup/software
Languages:
English, German, French, Spanish, Italian
Warranty:
5-year warranty
