Stored Images:
Up to 10,000
Vehicle Recognition:
Make: 70+ Model: 700+ Color 10
Available Countries:
USA, Canada, Mexico, Brazil, Uruguay, Paraguay, Argentina, Colombia, Chile *Additional countries available for other regions
Min. Illumination:
Color: 0.03Lux(F1.2, 1/30sec) B/W: 0.003Lux(F1.2, 1/30sec)
Video Out:
CVBS: 1.0 Vp-p / 75O composite, 720x480(N), 720x576(P) for installation USB: Micro USB Type B, 1280x720 for installation
Usage Type:
Parking; Community Traffic; City Traffic; Secondary Roads
Maximum Speed:
Low speed Up to 25MPH; Moderate speed Up to 45MPH; Moderate speed Up to 65MPH; Moderate speed Up to 75MPH
Lane Coverage:
2 lanes @Color (24ft Wide) 1 lane @Black & White with built-in IR; 2 lanes @Color (18ft Wide) 1 lane @Black & White built-in IR; Up to 2 lanes (18ft Wide); Up to 2 lanes (18ft Wide)
Maximum Forward Distance:
Color: 52ft Black & White w/ IR: 45ft; Color: 52ft Black & White w/ IR: 45ft; Color: 120ft Black & White: 120ft with ext. IR; Color: 120ft Black & White: 120ft with ext. IR
Maximum Horizontal Angle:
30°; 25°; 15°; 25°
Maximum Vertical Angle:
30°; 25°; 15°; 25°
Horizontal Offset:
Up to 24ft; Up to 18ft; Up to 24ft; Up to 12ft
Camera Install Height:
Up to 24ft; Up to 18ft; Up to 24ft; Up to 12ft
Applicable Model:
Dome/Bullet/Box; Dome/Bullet/Box; Box w/ enclosure; Box w/ enclosure
Imaging Device:
1/1.8" CMOS
Resolution:
3840x2160, 3072x1728, 2592x1944, 2688x1520, 2560x1440, 2048x1536, 1920x1080, 1600x1200, 1280x1024,1280x960, 1280x720, 1024x768, 800 x 600, 800 x 448, 720 x 576, 720x480, 640x480, 640x360
Max. Framerate:
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz)
Min. Illumination:
Color: 0.03Lux(F1.2, 1/30sec) B/W : 0.003Lux(F1.2, 1/30sec) IR OFF, B/W:0Lux IR LED on (850nm, 30° beam pattern)
Focus Control:
Simple focus
Lens Type:
DC auto iris, P iris, Manual, I-CS
Mount Type:
C mount, CS mount
Included lens:
SLA-T-M1250DN 12~50mm F1.8
Camera Title:
Displayed up to 85 characters
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, WDR, SSDR
Digital Noise Reduction:
SSNRV
Digital Image Stabilization:
Stabilization Support(built-in gyro sensor)
Motion Detection:
8ea, polygonal zones
Privacy Masking:
6ea, rectangle zones, Color: Gray/Black/White
Gain Control:
Low/ Middle / High
White Balance:
ATW/ AWC/ Manual / Indoor / Outdoor
LDC:
Support
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
Video Rotation:
Flip, Mirror, Hallway view(90/270)
Analytics:
Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Shock detection
Serial Interface:
RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell)
Alarm I/O:
Input 1ea / Output 1ea / DC 12V Power(Max. 50mA) 1ea
Alarm Triggers:
Analytics, Network disconnect, Alarm input
Alarm Events:
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output Handover, Audio playback
Audio In:
Selectable(mic in/line in/Built in mic) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out:
Line out, Max.output level: 1Vrms
Ethernet:
Metal shielded RJ-45(10/100/1000 BASE-T)
Video Compression:
H.265/H.264: Main/High, MJPEG
Audio Compression:
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz
Smart Codec:
Manual(5ea area), WiseStreamH
Bitrate Control:
H.264/H.265: CBRorVBR MJPEG: VBR
Streaming:
Unicast(6 users) / Multicast Multiple streaming(Up to 3 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast)
Security:
HTTPS(SSL) Login Authentication, Digest Login Authentication, IP Address Filtering , User access log, 802.1X Authentication(EAP-TLS, EAP-LEAP) Device Certificate(Hanwha Techwin Root CA) Secure boot
Application Programming Interface:
ONVIF Profile S/G/T SUNAPI(HTTPAPI) Wisenet open platform
Webpage Language:
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage:
Pre-installed with 32GB Micro SD to support 10,000 LPR images
Memory:
4096MBRAM,512MBFlash
Operating Temperature / Humidity:
-10°C ~ +55°C (14°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity:
-50°C ~ +60°C(-58°F ~ +140°F) / Lessthan90%RH
Input Voltage:
PoE+(IEEE802.3at) PoE+ board with IPM technology (Intelligent power management)
Power Consumption:
PoE+ Maximum 25.5W, at startup 23.5W, typical 22.8W
Ingress Protection:
IP66 / IP67
Color / Material:
Aluminum housing & mount, sunshield ABS, RAL9002 color
Product Dimensions / Weight:
6.30x20.24x6.93, Weight : 16.4lb
