Imaging Device:
1/1.8" CMOS
Resolution:
3840x2160, 3072x1728, 2592x1944, 2688x1520, 2560x1440, 2048x1536, 1920x1080, 1600x1200, 1280x1024,1280x960, 1280x720, 1024x768,; 800 x 600, 800 x 448, 720 x 576, 720x480, 640x480, 640x360
Max. Framerate:
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz); MJPEG: Max. 30fps/25fps(60Hz/50Hz)
Min. Illumination:
Color: 0.05Lux(F1.6, 1/30sec); BW: 0.005Lux(F1.6, 1/30sec), 0Lux(IR LED on)
Video Out:
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation; USB: Micro USB Type B, 1280x720 for installation
Focal Length (Zoom Ratio:
4.5~10mm(2.2x) motorized varifocal
Max. Aperture Ratio:
F1.6(Wide)~F2.65(Tele)
Angular Field of View:
H:101.4°(Wide)~45.5°(Tele) / V:53.6°(Wide)~25.5°(Tele) / D:120.7°(Wide)~52.3°(Tele)
Min. Object Distance:
0.5m(1.64ft)
Focus Control:
Simple focus
Lens Type:
P iris
Pan / Tilt / Rotate Range:
0˚~360˚ / -45˚~85˚ / 0˚~355˚
Camera Title:
Displayed up to 85 characters
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, WDR, SSDR
Digital Noise Reduction:
WiseNR Ⅱ(using AI engine); SSNRⅤ
Digital Image Stabilization:
Stabilization Support(built-in gyro sensor)
Motion Detection:
8ea, polygonal zones
Privacy Masking:
6ea, rectangle zones; - Color: Gray/Black/White
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor
LDC:
Support
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (1/5~1/12,000sec); Auto prefer shutter control based on AI engine
Video Rotation:
Flip, Mirror, Hallway view(90˚/270˚)
Analytics:
Classified object type: Person/Face/Vehicle/License plate; Attributes: Person(Gender, Color and Bag), Face(Age, Gender, Mask and Glasses), Vehicle(Type: car/bus/truck/motorcycle/bicycle and Color); Support BestShot per object; Analytics events based
Business Intelligence:
People/Vehicle/Crowd counting, Queue management, Heatmap based on AI engine
Alarm I/O:
2 configurable I/O ports, DC 12V output(Max. 50mA)
Alarm Triggers:
Analytics, Network disconnect, Alarm input, App event, Time schedule, MQTT subscription
Alarm Events:
When alarm trigger occurred; - File upload(image): e-mail/FTP; - Notification: e-mail; - Recording: SD/SDHC/SDXC or NAS recording at event triggers; - Alarm output; - Handover: PTZ preset, send message by HTTP/HTTPS/TCP; - Audio clip playback; - MQTT
Audio In:
Selectable(mic in/line in)
Audio Out:
Line out
Light Type:
IR LED (850nm)
IR Viewable Length:
WiseIR 30m(98.42ft)
Ethernet:
Metal shielded RJ-45(10/100/1000 BASE-T)
Video Compression:
H.265/H.264: Main/High, MJPEG
Audio Compression:
G.711 u-law /G.726 Selectable; G.726(ADPCM) 8KHz, G.711 8KHz; G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps; AAC-LC: 48Kbps at 16KHz
Smart Codec:
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(using AI engine)
Video Quality Adjustment:
H.264/H.265: Target bitrate level control; MJPEG: Target bitrate level control
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(6 users) / Multicast; Multiple streaming(Up to 6 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP(TCP, UDP Unicast), MQTT
Application Programming Interface:
ONVIF Profile S/G/T/M; SUNAPI(HTTP API); Wisenet open platform; - WiseAI application included(Analytic based on AI, Business intelligence)
OS / Firmware Protect:
Encrypted Firmware, Secure boot, Signed Firmware
User authentication:
Digest Authenticaton, Prevent brute-force attack
Network authentication:
IEEE 802.1X (EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2)
Secure Communication:
HTTPS, WSS (WebSocket Secure)
Access Control:
IP-based access control
Data Protect:
Encryption Credentials, Encrypt compress for live recording file
Audit:
Access / System / Event Log management
Device ID:
Device certificate (Hanwha Techwin Root CA)
Secure Storage:
SDcard partition encrypt
Webpage Language:
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese,; Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage:
Micro SD/SDHC/SDXC 2slots 512GB
Memory:
4096MB RAM, 512MB Flash
Operating Temperature / Humidity:
-25°C ~ +50°C (-13°F ~ +122°F) / Less than 90% RH
Storage Temperature / Humidity:
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH
Certification:
IP52, IK10, Plenum rate
Input Voltage:
PoE+(IEEE802.3at), 12VDC
Power Consumption:
PoE+: Max 20.00W, typical 16.00W; 12VDC: Max 17.70W, typical 14.00W
Color / Material:
White / Aluminum, Hard-coated dome bubble
RAL Code:
RAL9003
Product Dimensions / Weight:
Ø205x163mm(8.07x4.92"), Weight : 1.95Kg (4.30lb)
Detect (25PPM/ 8PPF:
Wide: 62.2m(204.04ft) / Tele: 185.4m(608.31ft)
Observe (63PPM/ 19PPF:
Wide: 24.9m(81.62ft) / Tele: 74.2m(243.32ft)
Recognize (125PPM/ 38PPF:
Wide: 12.4m(40.81ft) / Tele: 37.1m(121.66ft)
Identify (250PPM/ 76PPF:
Wide: 6.2m(20.40ft) / Tele: 18.5m(60.83ft)
Ver:
2
