Imaging Device:
1/2.8" CMOS
Resolution:
3328x1872, 3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate:
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz)
Min. Illumination:
Color: 0.1Lux(F1.6, 1/30sec) BW: 0.01Lux(F1.6, 1/30sec)
Focal Length (Zoom Ratio:
5~125mm(25x) zoom (digital 32x, total 800x zoom)
Max. Aperture Ratio:
F1.6(Wide)~F3.73(Tele)
Angular Field of View:
H: 57.42˚(Wide)~2.71˚(Tele) / V: 33.54˚(Wide)~1.55˚(Tele)
Min. Object Distance:
3m(9.84ft)
Focus Control:
Oneshot AF, Focus save
Lens Type:
DC auto iris
Pan Range:
360˚ Endless
Pan Speed:
Max. 700˚/sec, Manual: 0.024˚/sec~250˚/sec
Tilt Range:
110˚(-20˚~90˚)
Tilt Speed:
Max. 500˚/sec, Manual: 0.024˚/sec~250˚/sec
Sequence:
Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule
Preset Accuracy:
Up to '±0.1˚, Pan/Tilt correction
Camera Title:
Displayed up to 85 characters
Direction Indicator:
Support
Day & Night:
Auto(ICR)/Color/BW/Schedule
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
Extreme WDR(120dB)
Digital Noise Reduction:
SSNRⅤ
Digital Image Stabilization:
Support(built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
32ea, polygonal Support - Color: Grey/Green/Red/Blue/Black/White - Mosaic
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation:
Flip, Mirror
Analytics:
Directional detection, Fog detection, Face detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Shock detection * Audio detection, Sound classification(with NW I/O Box)
Alarm Triggers:
Analytics, Network disconnect * Alarm input(with NW I/O Box)
Alarm Events:
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers PTZ Preset Handover * Alarm output(with NW I/O Box)
Water Removal:
Support(Spinning dry)
Auto Tracking:
Object auto tracking(Person/Vehicle), Target lock tracking
Ethernet:
Metal shielded RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Smart Codec:
Manual(5ea area), WiseStreamⅡ
Video Quality Adjustment:
H.264/H.265: Target bitrate level control MJPEG: Target bitrate level control
Bitrate Control:
H.264/H.265: CBR or VBR MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast (128 user) Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour,LLDP, SRTP
Security:
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) Device certificate(Hanwha Techwin Root CA)
Application Programming Interface:
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform
Webpage Language:
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage:
Micro SD/SDHC/SDXC 2slot 1TB
Memory:
4GB RAM, 512MB Flash
Operating Temperature / Humidity:
Normal : -40°C~+55°C(-40°F ~ +131°F) / Maximum Temperature based on NEMA-TS 2(2.2.7) : +74°C(+165°F) * Start up should be done at above -30°C Less than 95% RH(Non-condensing)
Storage Temperature / Humidity:
-50°C~+60°C (-58°F~+140°F) / Less than 95% RH(Non-condensing)
Certification:
IP66, IK10, NEMA4X, NEMA-TS 2(2.2.8, 2.2.9)
Input Voltage:
PoE+(IEEE802.3at, Class4)
Power Consumption:
Typical 20W, Max 25W
Color / Material:
Body : White / Aluminum Head : Black / Polycarbontate Hard-coated dome
RAL Code:
White: RAL9003 / Black: RAL9005
Product dimensions / weight:
Ø158x293.3mm(6.22x11.55") / 3.2Kg(7.05lb)
Detect (25PPM/ 8PPF:
Wide: 121.5m(398.7ft) / Tele: 2813.9m(9232.1ft)
Observe (63PPM/ 19PPF:
Wide: 48.6m(159.5ft)/ Tele: 1125.6m(3692.8ft)
Recognize (125PPM/ 38PPF:
Wide: 24.3m(79.7ft)/ Tele: 562.8m(1846.4ft)
Identify (250PPM/ 76PPF:
Wide: 12.2m(39.9ft) / Tele: 281.4m(923.2ft)
