Imaging Device:
1/1.8" CMOS
Resolution:
2592x1520, 2560x1440, 1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate:
H.265/H.264: Max. 60fps/50fps(60Hz/50Hz)(WDR off); H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)(WDR on); MJPEG: Max. 30fps/25fps(60Hz/50Hz)(@4MP Max. 5fps)
Min. Illumination:
Color: 0.04 Lux(F1.36, 1/30sec, 30 IRE); BW: 0.004 Lux(F1.36, IR LED Off), 0Lux (IR LED On)
Focal Length (Zoom Ratio:
6.91 ~ 214.7mm(31x) zoom (digital 32x, total 992x zoom); Support Quick zoom
Max. Aperture Ratio:
F1.36(Wide)~F4.6(Tele)
Angular Field of View:
H : 59.4°(Wide)~2.54°(Tele); V : 35.8°(Wide)~1.49°(Tele); D : 68.2°(Wide)~2.95°(Tele)
Min. Object Distance:
3m(9.84ft)
Focus Control:
Oneshot AF, Focus save, Focus scan, Wise auto focus
Lens Type:
P-iris(IR corrected)
Pan Range:
360° Endless
Pan Speed:
Preset: 550°/sec, Manual: 0.024°/sec~200°/sec
Tilt Range:
110° (90° ~ -20°)
Tilt Speed:
Preset: 550°/sec, Manual: 0.024°/sec~200°/sec
Sequence:
Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule
Preset Accuracy:
±0.07° (±20°C by temperature at preset setting)
Camera Title:
Displayed up to 85 characters
Direction Indicator:
Support
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
120dB
Digital Noise Reduction:
WiseNRⅡ(Based on AI engine), SSNRⅤ
Digital Image Stabilization:
Support(built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
32ea, 4point quadrangle zones; - Color: Gray/Green/Red/Blue/Black/White; - Mosaic
Gain Control:
Off / Max gain / Manual
White Balance:
ATW / NarrowATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec); Prefer shutter control(Based on AI engine)
Video Rotation:
Flip&Mirror
Analytics:
Classified object type : Person/Face/Vehicle/License plate; Attributes : Vehicle(Type:car/bus/truck/motorcycle/bicycle); Support DetectionShot; Analytics events based on AI engine; - Object detection, Virtual line(Crossing/Direction), Virtual area(Lo
Alarm Triggers:
Analytics, Network disconnect, Alarm input((Via optional I/O box SPM-4210), Time schedule, MQTT subscription
Alarm Events:
When alarm trigger occurred; - File upload(image) : e-mail/FTP; - Notification : e-mail; - Recording : SD/SDHC/SDXC or NAS recording at event triggers; - Handover: PTZ preset, send message by HTTP/HTTPS/TCP; - MQTT: publication; * Alarm output / Audi
Light Type:
IR LED (850nm)
IR Viewable Length:
Wise IR 300m(984ft)
Water Removal:
Support(Spin dry, Lens heater)
Auto Tracking:
Support; Object auto tracking(Person/Vehicle); Target lock tracking
Ethernet:
Metal shielded RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Smart Codec:
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(Based on AI engine)
Video Quality Adjustment:
H.264/H.265: Target bitrate level control; MJPEG: Target bitrate level control
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast; Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast) , NTCIP 1205, MQTT
Application Programming Interface:
ONVIF Profile S/G/T/M; SUNAPI(HTTP API); Wisenet open platform
OS / Firmware Protect:
Secure boot, Signed firmware, Firmware encryption
User authentication:
Digest Authentication, Prevent brute-force attack
Network authentication:
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication:
HTTPS, SRTP, WSS(Websocket secure)
Access Control:
Access control based on IP address
Data Protect:
Authentication information encryption, ZIP compression encryption
Audit:
User Access/System/Event log management
Device ID:
Device Certificate(Hanwha Private Root CA)
Secure Storage:
TPM(Trusted platform module), HTPM(Hanwha trusted platform module),; SDcard partition encrypt
Security Certificate:
TPM with FIPS 140-2 level 2
Webpage Language:
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage:
Micro SD/SDHC/SDXC 2slot 1TB (512MBx2)
Memory:
4GB RAM, 512MB Flash
Operating Temperature / Humidity:
Normal : -50°C~+55°(-58°F ~ +131°F)/; +74°C(165°F)(Max) based on NEMA TS-2(2.2.7); * Start up should be done at above -30°C; 0~95% RH(Non-condensing)
Storage Temperature / Humidity:
-50°C~+60°C(-58°F~+140°F) / 0~90% RH
Certification:
IP66/IP67, IK10, NEMA4X; Safety(UL, KC-SDOC), EMC(FCC, CE, VCCI, RCM, KC); NEMA-TS 2(2.2.7, 2.2.8, 2.2.9)
Input Voltage:
HPoE(IEEE802.3bt type4, Class8, Injector included)
Power Consumption:
HPoE: Max 62W, typical 23W
Color / Material:
White / Aluminum
RAL Code:
RAL9003
Product Dimensions / Weight:
ø188x264.9mm(ø7.40x10.47") / 4400g (9.70lb)
Hanging Mount (Dome:
SBP-156HMW
Ceiling Mount (Assy:
SBP-156CMW, SBP-300CMTS, SBP-300CMW1/900CMW, SBP-150CMI/300CMI
Wall Mount:
SBP-156WMW, SBP-390WMW2
Pole Mount:
SBP-300PMW2
Parapet Mount:
SBP-156LMW, SBP-300LMW
Corner Mount:
SBP-156KMW, SBP-300KMW1
Cabinet:
SBP-300NBW
EMC:
FCC 47 CFR 15 Subpart B Class A; ICES-3(A)/NMB-3(A); CE/UKCA; - EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3; VCCI CISPR 32 Class A; RCM AS/NZS CISPR 32 Class A; KS C 9832 Class A , KS C 9835
Safety:
UL 62368-1, CAN/CSA C22.2 NO. 62368-1; IEC/EN 62471
Environment:
IEC/EN 63000; IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10; NEMA TS 2-2013 (2.2.7, 2.2.8, 2.2.9); NEMA 250 type 4X
Detect (25PPM/ 8PPF:
Wide: 90.9m(298.18ft) / Tele: 2338.4m(7671.81ft)
Observe (63PPM/ 19PPF:
Wide: 36.4m(119.27ft) / Tele: 935.3m(3068.72ft)
Recognize (125PPM/ 38PPF:
Wide: 18.2m(59.64ft) / Tele: 467.7m(1534.36ft)
Identify (250PPM/ 76PPF:
Wide: 9.1m(29.82ft) / Tele: 233.8m(767.18ft)
Ver:
202311
