Hanwha XNV-6081 (2MP) Day/Night Outdoor Vandal-Resistant 4mm Fixed Lens Dome IP Camera

$1,200.00
$780.00

Add to Cart for Sale Price!

$722.99
Description

The Hanwha XNV-6081 (2MP) Day/Night Outdoor Vandal-Resistant 4mm Fixed Lens Dome IP Camera is designed to provide advanced surveillance solutions for business and IT sectors, where security is paramount. This robust camera features a 2-megapixel high-resolution sensor, delivering crisp and clear imagery vital for accurate monitoring and identification purposes. Its 4mm fixed lens offers a wide field of view, ideal for overseeing extensive outdoor areas such as corporate campuses, retail exteriors, and parking lots. Built to endure, the XNV-6081 is housed in a vandal-resistant dome casing, ensuring it stands up to challenging outdoor conditions and potential tampering. Enhanced with day/night capabilities and equipped with superior IR illumination, this camera guarantees exceptional performance under varying lighting conditions, ensuring dependable 24/7 surveillance.

Distinguishing itself with state-of-the-art features, the XNV-6081 incorporates Wide Dynamic Range (WDR) technology, allowing it to capture balanced images in scenes with contrasting light levels. This ensures that both brightly illuminated and shadowed areas are visible with clarity, a critical feature for outdoor environments where lighting can be unpredictable. The camera's support for H.265/H.264 compression optimizes storage and bandwidth usage without compromising on video quality. Additionally, intelligent video analytics, including motion detection and tampering alerts, enhance security operations by facilitating real-time incident detection and alerts. Designed for seamless integration, the XNV-6081 is compatible with a wide range of network infrastructures and video management systems (VMS), making it a versatile and powerful addition to sophisticated security systems.

Key Features

  • 2 Megapixel High-Resolution Sensor: Provides sharp, detailed images for thorough surveillance coverage.
  • 4mm Fixed Lens: Offers a wide field of view for comprehensive monitoring of large outdoor areas.
  • Vandal-Resistant Dome Design: IK10-rated for enhanced durability against physical impact and tampering.
  • Day/Night Functionality with IR Illumination: Ensures high-quality images in low-light conditions and complete darkness.
  • Wide Dynamic Range (WDR): Balances exposure in high contrast scenes, maintaining image clarity across varying lighting conditions.
  • Efficient Video Compression: Utilizes H.265/H.264 formats for reduced storage and bandwidth needs while preserving video quality.
  • Intelligent Video Analytics: Motion detection and tampering alerts for proactive security monitoring and incident response.
  • Seamless Integration: Compatible with leading VMS platforms and supports standard network protocols for easy installation.

Compatibility

The Hanwha XNV-6081 is designed to integrate smoothly into various surveillance systems:

  • Video Management Software: Fully compatible with major VMS solutions for effective system management.
  • Network Protocols: Supports ONVIF, SIP, and other essential protocols for seamless connectivity with network infrastructure.
  • Storage Solutions: Compatible with MicroSD, NAS, and NVR storage options, providing flexible data management solutions.

Package Contents

  • Hanwha XNV-6081 Dome IP Camera
  • Quick Installation Guide
  • Mounting Hardware
  • Software CD-ROM for Device Management
  • Warranty and Safety Information

Summary

The Hanwha XNV-6081 Dome IP Camera emerges as a standout in the field of outdoor surveillance cameras, combining high-resolution imaging, durable construction, and advanced features. Designed for the demanding requirements of business and IT environments, it ensures extensive outdoor coverage with exceptional image quality under any lighting conditions. The camera's robust design, coupled with sophisticated analytics and efficient data management, make it an essential tool for enhancing security operations. With its ease of integration and broad compatibility, the XNV-6081 represents a smart, high-performing solution for organizations looking to strengthen their surveillance infrastructure with a reliable, feature-rich camera.

Specifications
Imaging Device: 1/2.8" 2MP CMOS
Resolution: 1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate: H.265/H.264: Max. 60fps/50fps(60Hz/50Hz); MJPEG: Max. 30fps/25fps(60Hz/50Hz)
Min. Illumination: Color: 0.015Lux(F1.4, 1./30sec); B/W: 0.0015Lux(F1.4, 1/30sec)
Video Out: CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation; USB: Micro USB Type B, 1280x720 for installation
Focal Length (Zoom Ratio: 2.8~12mm(4.3x) motorized varifocal
Max. Aperture Ratio: F1.4(Wide) ~ F3.6(Tele)
Angular Field of View: H: 119.5°(Wide)~27.9°(Tele) / V: 62.8°(Wide)~15.7°(Tele) / D: 142.1°(Wide)~32.0°(Tele)
Min. Object Distance: 0.5m(1.64ft)
Focus Control: Simple focus
Lens Type: DC auto iris, P iris
Pan / Tilt / Rotate Range: 0°~360° / -45°~85° / 0°~355°
Camera Title: Displayed up to 85 characters
Day & Night: Auto(ICR)
Backlight Compensation: BLC, HLC, WDR, SSDR
Wide Dynamic Range: 150dB
Digital Noise Reduction: SSNRⅤ
Digital Image Stabilization: Support(built-in gyro sensor)
Defog: Support
Motion Detection: 8ea, 8point polygonal zones
Privacy Masking: 32ea, polygonal zones; - Color: Grey/Green/Red/Blue/Black/White; - Mosaic
Gain Control: Low / Middle / High
White Balance: ATW / AWC / Manual / Indoor / Outdoor
LDC: Support
Electronic Shutter Speed: Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation: Flip, Mirror, Hallway view(90°/270°)
Analytics: Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification, Shock detection
Business Intelligence: People counting, Queue management, Heatmap
Alarm I/O: Input 1ea / Output 1ea
Alarm Triggers: Analytics, Network disconnect, Alarm input
Alarm Events: File upload via FTP and e-mail; Notification via e-mail; SD/SDHC/SDXC or NAS recording at event triggers; Alarm output; Handover; Audio playback
Audio In: Selectable(mic in/line in), Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out: Line out, Max. output level: 1Vrms
Ethernet: RJ-45(10/100BASE-T)
Video Compression: H.265/H.264: Main/Baseline/High, MJPEG
Audio Compression: G.711 u-law /G.726 Selectable; G.726(ADPCM) 8KHz, G.711 8KHz; G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps; AAC-LC: 48Kbps at 16KHz
Smart Codec: Manual(5ea area), WiseStreamⅡ
Bitrate Control: H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming: Unicast(20 users) / Multicast; Multiple streaming(Up to 10 profiles)
Protocol: IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP
Security: HTTPS(SSL) Login Authentication; Digest Login Authentication; IP Address Filtering; User access Log; 802.1X Authentication(EAP-TLS, EAP-LEAP)
Application Programming Interface: ONVIF Profile S/G/T; SUNAPI(HTTP API); Wisenet open platform
Web Viewer: Supported OS: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12; Recommended Browser: Google Chrome; Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only)
Edge Storage: Micro SD/SDHC/SDXC 2slot 512MB
Memory: 1024MB RAM, 256MB Flash
Operating Temperature / Humidity: -50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH; * Start up should be done at above -35°C
Storage Temperature / Humidity: -50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH
Certification: IP66/IP67/IP6K9K, IK10+, NEMA4X
Input Voltage: PoE(IEEE802.3af, Class3), 24VAC(Optional), 12VDC
Power Consumption: PoE: Max 7.0W, typical 4.90W; 12VDC: Max 5.4W, typical 3.70W; 24VAC: Max 7.1W, typical 4.90W
Color / Material: White / Aluminum
RAL Code: RAL9003
Product Dimensions / Weight: Ø180x125mm(7.09x4.92"), 1.45kg(3.20 lb)
