Imaging Device:
1/2.8" progressive CMOS
Resolution:
3328x1872, 3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate:
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 15fps/12fps(60Hz/50Hz)
Min. Illumination:
Color: 0.05Lux(F1.2, 1/30sec, 30IRE) B/W: 0.005Lux(F1.2, 1/30sec, 30IRE), 0Lux(IR LED on)
Video Out:
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation USB: Micro USB Type B, 1280x720 for installation
Focal Length (Zoom Ratio:
2.8~8.4mm(3x) motorized varifocal
Max. Aperture Ratio:
F1.2(Wide)~F2.8(Tele)
Angular Field of View:
H: 114°(Wide)~40.2°(Tele) V: 62.0°(Wide)~22.5°(Tele) D: 133.0°(Wide)~46.3°(Tele)
Min. Object Distance:
0.7m (2.23ft)
Focus Control:
Simple focus
Lens Type:
DC Auto Iris, P iris
Pan / Tilt / Rotate Range:
0˚~360˚ / -45˚~85˚ / 0˚~355˚
Camera Title:
Displayed up to 85 characters
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
extremeWDR (120dB)
Digital Noise Reduction:
SSNRⅤ
Digital Image Stabilization:
Support(built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, 8point Polygonal zones
Privacy Masking:
32ea, Quadrangle zones - Color : Gray, Green, Red, Blue, Black, White - Mosaic
Gain Control:
Support
White Balance:
ATW / Narrow ATW / AWC / Manual / Indoor / Outdoor
LDC:
Support (Fill/stretch mode)
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec) prefer shutter control
Video Rotation:
Flip, Mirror, Hallway view(90°/270°)
Analytics:
Defocus detection, Directional detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Fog detection, Virtual line, Audio detection, Sound classification, Shock detection, Face/upper body detection
Business Intelligence:
People counting, Queue management, Heatmap
Alarm I/O:
2 configurable I/O ports
Alarm Triggers:
Analytics, Network disconnect, Alarm input
Alarm Events:
When alarm trigger occurred - File upload(image) : e-mail/FTP - Notification : e-mail - Recording : SD/SDHC/SDXC or NAS recording at event triggers - Alarm output - Handover(PTZ preset, Send message by HTTP/HTTPS/TCP) - Audio clip playback
Audio In:
Selectable(mic in/line in) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out:
Line out, Max.output level: 1Vrms
IR Viewable Length:
WiseIR 40m(131.23ft)
Ethernet:
Metal shielded RJ-45(10/100/1000BASE-T)
Video Compression:
H.265/H.264: Main/High, MJPEG
Audio Compression:
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz
Smart Codec:
Manual(5ea area), WiseStreamⅡ
Bitrate Control:
H.264/H.265: CBR or VBR MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles, 3 virtual channel support)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast)
Security:
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) Device Certificate(Hanwha Techwin Root CA, pre-installed) Secure by default certificate HTPM
Application Programming Interface:
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform
Webpage Language:
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Greek, Hungarian
Edge Storage:
Micro SD/SDHC/SDXC 2slot 1TB(512GBx2)
Memory:
4GB RAM, 512MB Flash
Operating Temperature / Humidity:
-50°C ~ +60°C(-58°F ~ +140°F) / 0 ~ 95% RH(non condensing) * Start up should be done at above -30°C
Storage Temperature / Humidity:
-50°C ~ +60°C(-58°F ~ +140°F) / 0 ~ 90% RH
Certification:
IP66/IP67/IP6K9K, IK10+, NEMA4X
Input Voltage:
PoE(IEEE802.3af), 12VDC, 24VAC(Accessory)
Power Consumption:
PoE : Max 12.95W, typical 10.7W 12VDC : Max 11.5W, typical 9.0W 24VAC : Max 13.5W, typical 11.0W Power redundancy failover
Color / Material:
White / Aluminum, Hard-coated dome bubble
RAL Code:
RAL9003
Product Dimensions / Weight:
Ø180x125mm(7.09x4.92"), 1900g(4.19 lb)
Compatible Conduit hole / Gangbox:
3/4" (M25) single, double, 4" octagon, 4" square
Hanging Mount (Dome:
SBP-187HMW
Detect (25PPM/ 8PPF:
Wide: 43.2m(141.81ft) / Tele: 181.9m(596.73ft)
Observe (63PPM/ 19PPF:
Wide: 17.3m(56.73ft) / Tele: 72.8m(238.69ft)
Recognize (125PPM/ 38PPF:
Wide: 8.6m(28.36ft) / Tele: 36.4m(119.35ft)
Identify (250PPM/ 76PPF:
Wide: 4.3m(14.18ft) / Tele: 18.2m(59.67ft)
