Image Sensor:
1/1.8" Progressive Scan CMOS
Max. Resolution:
2688 × 1520
Min. Illumination:
Color: 0.0005 Lux @ (F1.2, AGC ON); B/W: 0.0001 Lux @ (F1.2, AGC ON)
Shutter Time:
1 s to 1/100,000 s
Day & Night:
IR cut filter;Blue glass module to reduce ghost phenomenon
Lens Mount:
CS mount
Model Specification:
Up to 4 models, Model type: detection model, classification model, mixed model (detection model and classification model)
Main Stream:
50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720);50 fps (2560 × 1440, 1920 × 1080, 1280 × 720);60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720);60 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (704 × 480, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480)
Third Stream:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480);60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream:
50 Hz: 25 fps (704 × 480, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480)
Fifth Stream:
50 Hz: 25 fps (704 × 480, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, Fourth stream: H.265/H.264/MJPEG, Fifth stream: H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 8 Mbps
H.264 Type:
Baseline Profile,Main Profile,High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR,VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
4 fixed regions for each stream
Target Cropping:
Yes
E-PTZ:
Support Patrol and Auto Tracking settings
Audio Type:
Mono sound
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate:
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering:
Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
Simultaneous Live View:
Up to 20 channels
API:
Open Network Video Interface (Profile S, Profile G, Profile T, Profile M),ISAPI,SDK,ISUP
User/Host:
Up to 32 users;3 user levels: administrator, operator, and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Inter
Network Storage:
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200,Hik-Connect,Hik-Central
Web Browser:
Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Parameters Switch:
Yes
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, white balance, and AGC adjustable by client software or web browser
Day/Night Switch:
Day,Night,Auto,Schedule,Alarm Trigger
Wide Dynamic Range (WDR:
140 dB
Image Enhancement:
BLC,HLC,3D DNR,Distortion Correction,Defog
SNR:
≥ 52 dB
Privacy Mask:
8 programmable polygon privacy masks
Image Stabilization:
EIS
Picture Overlay:
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
Video Output:
1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
Ethernet Interface:
1 RJ45 100 M/1000 M self-adaptive Ethernet port
On-Board Storage:
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB
Audio:
1 input (line in), 1 output (line out), 3.5 mm connector
Built-In Microphone:
Yes,1 built-in microphone
Alarm:
2 inputs, 2 outputs (max. 24 VDC, 1 A)
RS-485:
1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset Key:
Yes
Power Output:
12 VDC, max. 100 mA
Fiber Optical:
With /F11: 1 LC fiber optical interface, SFP module, single mode, 20 km transmission distance, 1310 nm (TX) and 1550 nm (RX), 155 Mbps transmission rate
Basic Event:
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),video quality diagnosis
Smart Event:
scene change detection,audio exception detection,defocus detection
Linkage:
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning
Multi-Target-Type Detection:
Supports simultaneous detection and capture of human body, face, and vehicle, Gets 7 face features, Gets 13 human body features, Gets 2 vehicle features, Supports counting the number of line crossing targets by type, including human body, non-motor v
Face Capture:
Detects up to 120 faces simultaneously, captures up to 40 face pictures per frame simultaneously and uploads up to 10 face pictures per second, Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°, Uploads face with backg
Face Comparison:
Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total, Supports face library encryption
Perimeter Protection:
Line crossing, intrusion, region entrance, region exiting;Support alarm triggering by specified target types (human and vehicle);Support combined event alarm triggering
People Counting:
Supports Multi-Dimension People Counting, Supports counting, displaying and exporting the people flow data of entering, exiting and passing by (The data is stored in the flash.), Supports real-time uploading and uploading by statistic cycle, Supports
Queue Management:
Supports up to 8 detection regions, and independent arming schedule and linkage method;Supports 2 detection modes: regional people queuing-up, waiting time detection;Generates reports to compare the efficiency of different queuing-ups and display the
Heat Map:
A graphic description of visits (by calculating amount of people or amount of dwell time) in a configured area., Two report types are available, space heat map and time heat map line chart.
Hard Hat Detection:
Detects up to 30 human targets simultaneously;Supports up to 4 shield regions
Metadata:
Intrusion detection,line crossing detection,region entrance detection,region exiting detection,face capture,multi-target-type detection
Regional People Counting:
Supports up to 8 detection regions, and independent arming schedule and linkage method;Supports 3 detection modes: people density detection, number of people exception detection, waiting time exception detection;Supports parameter settings: alarm tim
On/Off Duty Detection:
Supports up to 8 detection regions, and independent arming schedule and linkage method;Supports 2 detection modes: absence detection, on/off duty detection;Supports parameter settings: person on duty, absence duration
Power:
With F11: 12 VDC ± 20%, 0.95 A, max. 11.3 W, two-core terminal block;24 VAC ± 20%, 0.49 A, max. 11.6 W, two-core terminal block;PoE: IEEE 802.3af, Type 1, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.3 W;Without /F11: 12 VDC ± 20%, 0.9 A, max. 10
Material:
Aluminum alloy body
Dimension:
142.5 mm × 69.8 mm × 68 mm (5.61" × 2.75" × 2.68")
Package Dimension:
315 mm × 140 mm × 140 mm (12.4" × 5.51" × 5.51")
Weight:
Approx. 730 g (1.96 lb.)
With Package Weight:
Approx. 1115 g (2.99 lb.)
Storage Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language:
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Tradition
General Function:
Heartbeat, mirror, password protection, one-key reset
Device Management:
Supports adding alarm box (DS-FM2466) in the LAN to expand 6 additional input and 6 output alarm interfaces
EMC:
FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
Safety:
UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1
Environment:
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
CC:
Common Criteria, Assurance Level: EAL2 + ALC_FLR.2
EMC:
FCC: 47 CFR Part 15, Subpart B,CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,RCM: AS/NZS CISPR 32: 2015,IC: ICES-003: Issue 7,KC: KN32: 2015, KN35: 2015
Safety:
UL: UL 62368-1,CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017,BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,LOA: IEC/EN 60950-1
