Image Sensor:
1/1.8" Progressive Scan CMOS
Max. Resolution:
3840 × 2160
Min. Illumination:
Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Time:
1/3 s to 1/100,000 s
Day & Night:
IR cut filter
Angle Adjustment:
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens Type:
Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV:
2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131°;4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102°;6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 60°
Lens Mount:
M12
Iris Type:
Fixed
Aperture:
F1.6
DORI:
2.8 mm: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m;4 mm: D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m;6 mm: D: 140.0 m, O: 55.6 m, R: 28.0 m, I: 14.0 m
Supplement Light Type:
IR
Supplement Light Range:
Up to 30 m
Smart Supplement Light:
Yes
IR Wavelength:
850 nm
Main Stream:
50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720);60 Hz: 24 fps (3840 × 2160);30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (640 × 480, 640 × 360);60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream:
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);*Third stream is supported under certain settings.
Video Compression:
Main stream: H.265/H.264/H.264+/H.265+;Sub-stream: H.265/H.264/MJPEG;Third stream: H.265/H.264;*Third stream is supported under certain settings.
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR/VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
1 fixed region for main stream and sub-stream
Target Cropping:
Yes
Audio Type:
-U: mono sound
Audio Compression:
-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
Audio Bit Rate:
-U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC)
Audio Sampling Rate:
-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering:
-U: Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP
Simultaneous Live View:
Up to 6 channels
API:
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
User/Host:
Up to 32 users. 3 user levels: administrator, operator and user
Security:
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage:
MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR);Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE 10+;Plug-in free live view: Chrome 57.0+, Firefox 52.0+;Local service: Chrome 57.0+, Firefox 52.0+
Image Parameters Switch:
Yes
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch:
Day, Night, Auto, Schedule
Wide Dynamic Range (WDR:
120 dB
SNR:
≥ 52 dB
Image Enhancement:
BLC, HLC, 3D DNR
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:
Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Built-In Microphone:
-U: Yes
Reset Key:
Yes
Basic Event:
Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event:
Scene change detection
Linkage:
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture
Face Capture:
Yes
Power:
12 VDC ± 25%, 0.48 A, max. 5.8 W, Ø5.5 mm coaxial power plug, reverse polarity protection;PoE: 802.3af, Class 3, 36 V to 57 V, 0.19 A to 0.12 A, max. 6.8 W
Dimension:
Ø138.3 mm × 126.3 mm (Ø5.4" × 5")
Package Dimension:
170 mm × 170 mm × 150 mm (6.9" × 6.9" × 5.9")
Weight:
Approx. 740 g (1.6 lb.)
With Package Weight:
Approx. 1020 g (2.2 lb.)
Storage Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions:
-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
Language:
33 languages;English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditiona
General Function:
Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
EMC:
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015)
Safety:
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
Environment:
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection:
IP67 (IEC 60529-2013)
