Image Sensor:
1/2.9" Progressive Scan CMOS
Min. Illumination:
Color: 0.028 lux @(F2.0, AGC ON), 0 lux with IR on
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120 dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: -30° to 30°, tilt: 0° to 75°, rotate: 0° to 360°
Lens Type:
2.8, 4, 6 mm
FOV:
2.8 mm, horizontal FOV: 97°, vertical FOV: 67°, diagonal fov: 121°;4 mm, horizontal FOV: 78°, vertical FOV: 53°, diagonal FOV: 98°;6 mm, horizontal FOV: 60°, vertical FOV: 41°, diagonal FOV: 76°
Aperture:
F2.0
Lens Mount:
M12
IR Range:
Up to 10 m
Wavelength:
850 nm
Max. Resolution:
3072 × 2048
Main Stream:
50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656);25 fps (2560 × 1440, 1920 × 1080, 1280 × 720);60Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656);30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream:
50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240);60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
Third Stream:
50Hz: 25 fps (1280 × 720, 640 × 360, 352 × 288);60Hz: 30 fps (1280 × 720, 640 × 360, 352 × 240)
Video Compression:
Main stream: H.265/H.264;Sub-stream: H.265/H.264/MJPEG;Third stream: H.265/H.264
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream supports
H.265:
Main stream supports
Scalable Video Coding (SVC:
Support H.264 and H.265 encoding
Environment Noise Filtering:
Yes
Audio Sampling Rate:
16 kHz, 32kHz, 44.1kHz, 48kHz
Audio Compression:
G722.1/G711ulaw/G711alaw/G726/MP2L2/PCM
Audio Bit Rate:
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome
Protocols:
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
User/Host:
Up to 32 users. 3 levels: administrator, operator and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network Storage:
Support Micro SD/SDHC/SDXC card (128 GB), local storage and NAS (NFS, SMB/CIFS), ANR
Client:
Wired network: Hik-Connect, iVMS-4200, Hik-Central;Wi-Fi: iVMS-4200, Hik-Central;*Wi-Fi connection with Hik-Connect directly is not possible.
Web Browser:
Plug-in required live view: IE8+;Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+;Local Service: Chrome 41.0+, Firefox 30.0+
Alarm Trigger:
Motion detection, video tampering, network disconnected, IP address conflict, HDD full, HDD error, illegal login
Encryption Mode:
-W: WPA, WPA2
Wi-Fi Protocol:
-W: IEEE 802.11b/g/n
Frequency Range:
-W: 2.412 GHz to 2.4835 GHz
Channel Bandwidth:
-W: 20 MHz
Transfer Rate:
-W: 11b: 11 Mbps;11g: 54 Mbps;11n: up to 150 Mbps
Wireless Range:
-W: Up to 50 m (The performance varies based on actual environment)
Day/Night Switch:
Auto/Schedule/Day/Night/Triggered by Alarm In (-S)
Image Enhancement:
BLC/3D DNR/HLC
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
Audio:
-S: 2 inputs: line in or mic in (built-in microphone);1 output: line out, mono sound, terminal block
Alarm:
-S: 1 input: alarm in;1 output: alarm out (max. 12 VDC, 30 mA), terminal block
On-Board Storage:
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, intrusion detection, face detection
Face Detection:
Yes
Linkage Method:
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output , Email
Firmware Version:
V5.6.5
Web Client Language:
32 languages;English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditiona
General Function:
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Startup And Operating Conditions:
-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
Power Supply:
12 VDC ± 25%;PoE (802.3af, class 3)
Power Consumption And Current:
12 VDC, 0.7 A, max. 8.5 W, Φ 5.5mm coaxial plug power;PoE (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max. 10 W
Camera Dimension:
Ø120 mm × 67.4 mm (Ø4.7" × 2.7")
Camera Weight:
Camera: approx. 400 g (0.9 lb.)
Protection:
Ingress protection: IP66 (IEC 60529-2013), IK08 (IEC 60529-2013)
