Image Sensor:
1/1.8" Progressive Scan CMOS
Min. Illumination:
Color: 0.002 Lux @ (F1.2, AGC ON), 0.004 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed:
1 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
140 dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
Focus:
Auto, semi-auto, manual
Lens Type:
Motorized lens, 2.8 to 12 mm and 8 to 32 mm optional
FOV:
2.8 to 12 mm, horizontal FOV 103.3° to 38.6°, vertical FOV 54.2° to 21.9°, diagonal FOV 124.2° to 44.3°;8 to 32 mm, horizontal FOV 42.5° to 13.4°, vertical FOV 23.4° to 7.7°, diagonal FOV 49° to 15.3°
Aperture:
F1.2 to 2.5;8 to 32 mm: F1.6, Constant F1.6 throughout the zoom range
Lens Mount:
Integrated
Aperture Type:
P-iris
IR Range:
2.8 to 12 mm: up to 30 m; 8 to 32 mm: up to 50 m
Wavelength:
850 nm
Max. Resolution:
1920 × 1080
Main Stream:
50Hz: 50fps (1920 × 1080, 1280 × 960, 1280 × 720);60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream:
50Hz: 25fps (704 × 576, 640 × 480),60Hz: 30fps (704 × 480, 640 × 480)
Third Stream:
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480),60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream:
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480),60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream:
50Hz: 25fps (704 × 576, 640 × 480),60Hz: 30fps (704 × 480, 640 × 480)
Custom Stream:
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480),60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression:
Main stream: H.265/H.264/H.265+/H.264+,Sub stream/third stream/fourth stream/fifth stream/custom stream: H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream support
H.265:
Main stream support
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
Main stream/sub stream/third stream/fourth stream/fifth stream: 4 fixed regions for each stream
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate:
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/ 8-320Kbps(MP3)
Simultaneous Live View:
Up to 20 channels
API:
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Smooth Streaming:
Yes
User/Host:
Up to 32 users, 3 levels: administrator, operator and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTT
Network Storage:
microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR;Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200, Hik-Connect, iVMS-5200, Hik-Central
Web Browser:
Plug-in required live view: IE8-11, Chrome 41-44, Mozilla Firefox30.0-51, Safari8.0+,Plug-in free live view: Chrome 45+, Mozilla Firefox52+
Alarm Trigger:
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by Alarm In
Target Cropping:
Yes
Picture Overlay:
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Image Enhancement:
BLC, HLC, 3D DNR, Defog, EIS, distortion correction
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
SNR:
≥52dB
Audio:
1-ch 3.5 mm input (line in), 1-ch 3.5mm output, mono
Alarm:
1-ch input, 1-ch output (up to 24 VDC 1A or 110 VAC 500 mA)
Video Output:
1Vp-p composite output (75 Ω/CVBS)
On-Board Storage:
Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M/1000M Ethernet port,1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Power Output:
12 VDC, max. 200 mA
Interface Style:
Connector panel
Heater:
Heater -H: yes
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, up to 4 lines configurable;Intrusion detection, up to 4 regions configurable;Region entrance detection, up to 4 regions configurable;Region exiting detection, up to 4 regions configurable;Unattended baggage detection, up to 4
Counting:
Counting
Linkage Method:
Trigger recording：memory card, network storage, pre-record and post-record;Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email;Trigger notification: HTTP, ISAPI, alarm output, Email
Firmware Version:
5.6.0
Web Client Language:
32 languages;English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditiona
General Function:
Anti-flicker, 5 streams and up to 5 custom streams, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter, HTTP listening
Embedded Open Platform:
Yes. The camera supports installation and running up to 4 extra applications.
Storage Conditions:
-30 °C to 65 °C (-22 °F to 149 °F), humidity 95% or less (non-condensing)
Startup And Operating Conditions:
-IZS: -30 °C to 65 °C (-22 °F to 149 °F), humidity 95% or less (non-condensing);-IZHS: -40 °C to 65 °C (-40 °F to 149 °F), humidity 95% or less (non-condensing)
Power Supply:
12 VDC is recommended, 10 to 48 VDC; reverse polarity protection; two-core terminal block; PoE (802.3at, class 4)
Power Consumption And Current:
-IZS: With extra load: 12 VDC, 1.27 A, max. 15.2 W; PoE (802.3at, 42.5 V to 57 V), 0.36 A to 0.27 A, class 4;Without extra load: 12 VDC, 1.05 A, max. 12.6 W; PoE (802.3at, 42.5 V to 57 V), 0.3 A to 0.23 A, class 4;-IZHS: With extra load: 12 VDC, 1.4
Camera Dimension:
Camera: Φ162 × 140.3 mm (Φ6.4" × 5.5");With package: 251 × 215 × 189 mm (9.9" × 8.5" × 7.4")
Camera Weight:
Camera: 1450 g (3.2 lb.);With package: 1950 g (4.3 lb.)
EMC:
IC: IC-VoC(ICES-003 Issue 7:2020), FCC: FCC-SDoC(ANSI C63.4,FCC Part15 sub B), KC: KN 301489-1,KN 301489-17,RRA NOTICE 2017-14(2017.12.05),RRA NOTICE 2017-19(2017.12.28), CE: CE-EMC(EN 50130-4:2011+A1:2014,EN 55032:2015,EN 61000-3-2:2014,EN 61000-3-3
Safety:
CB: IEC 60950-1, UL: UL 60950-1:2014,CAN/CSA C22.2 No. 60950-1-07:2014, LOA: SANS IEC60950-1
Environment:
CE: CE-RoHS(RoHS Directive 2011/65/EU+2015/863);REACH SVHC: Regulation (EC) No 1907/2006
Protection:
Ingress protection: IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
EMC:
IC: IC-VoC(ICES-003 Issue 7:2020), FCC: FCC-SDoC(ANSI C63.4,FCC Part15 sub B), KC: KN 301489-1,KN 301489-17,RRA NOTICE 2017-14(2017.12.05),RRA NOTICE 2017-19(2017.12.28),CE: CE-EMC(EN 50130-4:2011+A1:2014,EN 55032:2015,EN 61000-3-2:2014,EN 61000-3-3:
Safety:
CB: IEC 60950-1,UL: UL 60950-1:2014,CAN/CSA C22.2 No. 60950-1-07:2014,LOA: SANS IEC60950-1
Environment:
CE: CE-RoHS(RoHS Directive 2011/65/EU+2015/863)REACH SVHC: Regulation (EC) No 1907/2006
