Image Sensor:
1/1.8" Progressive Scan CMOS
Min. Illumination:
Color: 0.007 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Speed:
1 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120 dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Bracket, pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360°
Focus:
Auto, semi-auto, manual
Lens Type:
2.8 to 12 mm
FOV:
2.8 to 12 mm, horizontal FOV 112.4° to 41°, vertical FOV 58° to 23°, diagonal FOV 137° to 47°
Aperture:
F1.2
Lens Mount:
Integrated
IR Range:
Up to 50 m
Wavelength:
850 nm
Max. Resolution:
3840 × 2160
Main Stream:
50Hz: 25fps (3840 × 2160, 3200 × 1800, 2560 × 1440, 1920 × 1080, 1280 × 720),60Hz: 30fps (3840 × 2160, 3200 × 1800, 2560 × 1440, 1920 × 1080, 1280 × 720),
Sub-Stream:
50Hz: 25fps (704 × 576, 640 × 480),60Hz: 30fps (704 × 480, 640 × 480),
Third Stream:
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480),60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream:
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480),60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream:
50Hz: 25fps (704 × 576, 640 × 480),60Hz: 30fps (704 × 480, 640 × 480)
Custom Stream:
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480),60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480),Up to 5 custom streams are supported
Video Compression:
Main stream: H.265/H.264/H.265+/H.264+,Sub stream/third stream/fourth stream/fifth stream/custom stream: H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream supports
H.265:
Main stream supports
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
4 fixed regions for main stream, sub stream, third stream, fourth stream, and fifth stream, and dynamic face tracking
Environment Noise Filtering:
No
Audio Sampling Rate:
No
Audio Compression:
No
Audio Bit Rate:
No
Simultaneous Live View:
Up to 20 channels
API:
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
User/Host:
Up to 32 users. 3 user levels: administrator, operator and user
Security:
Password protection, HTTPS encryption, IEEE 802.1x port-based network access control, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF
Network Storage:
microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR
Client:
iVMS-4200, Hik-Connect, iVMS-5200, Hik-Central
Web Browser:
Plug-in required live view: IE8-11, Chrome 41-44, Mozilla Firefox30.0-51, Safari8.0+,Plug-in free live view: Chrome 45+, Mozilla Firefox52+
Alarm Trigger:
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Day/Night Switch:
Day/Night/Auto/Schedule/Triggered by Alarm In
Target Cropping:
Yes
DNR:
3D DNR
Picture Overlay:
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Image Enhancement:
BLC, HLC, 3D DNR, Defog, EIS
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Audio:
No
Alarm:
2 inputs, 2 outputs (up to 24 VDC 1A or 110 VAC 500 mA)
Video Output:
1 BNC: CVBS analog output (4CIF resolution), internal,1Vp-p composite output (75 Ω/CVBS)
On-Board Storage:
Built-in microSD/SDHC/SDXC slot, up to 256 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M/1000M Ethernet port
Heater:
-H: yes
Smart Event:
Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection
Counting:
Counting
Face Detection:
Yes
Exception Detection:
Scene change detection, defocus detection
Firmware Version:
5.5.80
General Function:
One-key reset, anti-flicker, 5 streams and up to 5 custom streams, heartbeat, password protection, privacy mask, watermark, IP address filter
Startup And Operating Conditions:
-30 °C to 65 °C (-22 °F to 149 °F), -H: -40 °C to 65 °C (-40 °F to 149 °F),Humidity 95% or less (non-condensing)
Power Supply:
12 VDC ± 20%, two-core terminal block,PoE (802.3at, class 4)
Power Consumption And Current:
-IZS: 12 VDC, 1.0 A, max. 12 W; PoE (802.3at, 42.5 V to 57 V), 0.3 A to 0.2 A,-IZHS: 12 VDC, 1.3 A, max. 15 W; PoE (802.3at, 42.5 V to 57 V), 0.4 A to 0.3 A
Camera Dimension:
Camera: Φ144 × 347 mm (Φ5.7" × 13.7"),With package: 405 × 190 × 180 mm (15.9" × 7.5" × 7.1")
Camera Weight:
Camera: approx. 2.45 kg (5.40 lb.),With package: approx. 2.7 kg (5.95 lb.)
EMC:
RCM: AS/NZS CISPR 32: 2015, IC: IC-VoC(ICES-003 Issue 7:2020), FCC: FCC-SDoC(ANSI C63.4,FCC Part15 sub B), KC: KN32:2015,KN35:2015, CE: CE-EMC(EN 50130-4:2011+A1:2014,EN 55032:2015,EN 61000-3-2:2014,EN 61000-3-3:2013)
Safety:
CB: IEC 60950-1, UL: UL 60950-1:2014,CAN/CSA C22.2 No. 60950-1-07:2014, LOA: SANS IEC60950-1, BIS: IS 13252(Part 1)2010+A1:2013+A2:2015, CE: CE-LVD(EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013)
Environment:
CE: CE-RoHS(RoHS Directive 2011/65/EU+2015/863);REACH SVHC: Regulation (EC) No 1907/2006
Protection:
IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
Environment:
CE: CE-RoHS(RoHS Directive 2011/65/EU+2015/863)REACH SVHC: Regulation (EC) No 1907/2006
