Image Sensor:
1/1.7" Progressive Scan CMOS
Max. Resolution:
4000 × 3000
Min. Illumination:
Color: 0.009 Lux @ (F1.2, AGC ON); B/W: 0.0009 Lux @ (F1.2, AGC ON)
Shutter Time:
1 s to 1/100,000 s
Day & Night:
IR cut filter;Blue glass module to reduce ghost phenomenon.
Angle Adjustment:
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
Iris Type:
P-iris
Focus:
Auto, semi-auto, manual
Focal Length & FOV:
2.8 to 12 mm, horizontal FOV 96° to 46.2°, vertical FOV 69.2° to 27.2°, diagonal FOV 131° to 45.2°;8 to 32 mm, horizontal FOV 37.8° to 13.6°, vertical FOV 27.8° to 10.3°, diagonal FOV 48.6° to 17.4°
Aperture:
2.8 to 12mm: F1.2 to F2.5;8 to 32 mm: F1.7 to F1.73
Lens Mount:
Integrated
Supplement Light Type:
IR
Supplement Light Range:
2.8 to 12 mm: 30 m;8 to 32 mm: 50 m
IR Wavelength:
850 nm
Smart Supplement Light:
Yes
Main Stream:
50 Hz: 25 fps (4096 × 2160, 3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720);60 Hz: 30 fps (4096 × 2160, 3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720);50 Hz: 20 fps (4000 × 3000);60 Hz: 20 fps (4000 × 3000)
Sub-Stream:
50 Hz: 25 fps (704 × 576, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480)
Third Stream:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480);60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480);60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream:
50 Hz: 25 fps (704 × 576, 640 × 480);60 Hz: 30 fps (704 × 480, 640 × 480)
Custom Stream:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480);60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264;Sub-stream/third stream/fourth stream/fifth stream/custom stream: H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR/VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
4 fixed regions for each stream
Target Cropping:
Yes
Environment Noise Filtering:
Yes
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate:
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/32 Kbps (PCM)/8 to 320 Kbps (MP3)
Audio Type:
Mono sound
Simultaneous Live View:
Up to 20 channels
API:
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Smooth Streaming:
Yes
User/Host:
Up to 32 users. 3 user levels: administrator, operator and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP OVER HTT
Network Storage:
NAS (NFS, SMB/CIFS), auto network replenishment (ANR);Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE8+;Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+;Local service: Chrome 41.0+, Firefox 30.0+
Wide Dynamic Range (WDR:
Digital WDR
Day/Night Switch:
Day, Night, Auto, Schedule, Alarm Trigger
Picture Overlay:
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format
Image Enhancement:
BLC, HLC, 3D DNR, Defog, EIS, Distortion Correction
Image Parameters Switch:
Yes
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
SNR:
≥52 dB
Alarm:
1 input, 1 output (max. 24 VDC, 1 A)
Audio:
Without -R: 1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type:
RS-485:
With -Y: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Video Output:
1 Vp-p Composite Output(75 Ω/CVBS) (For debugging only)
On-Board Storage:
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Reset Key:
Yes
Ethernet Interface:
1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
Power Output:
12 VDC, max. 100 mA (supported by all power supply types)
Basic Event:
Motion detection, video tampering alarm, vibration detection, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Linkage:
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture; Trigger recording: memory card, network storage, pre-record and post-record; Trigger captured pictures uploading: FTP, SF
Smart Event:
Line crossing detection, up to 4 lines configurable;Intrusion detection, up to 4 regions configurable;Region entrance detection, up to 4 regions configurable;Region exiting detection, up to 4 regions configurable;Unattended baggage detection, up to 4
Face Capture:
Detects up to 30 faces simultaneously; Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°; Up to 3 face libraries with up to 30000 faces each are configurable; Recognizes face identity via face modeling, grading and com
Multi-Target-Type Detection:
Supports simultaneous detection of human body and face; Gets 8 face features and 13 human body features.
Hard Hat Detection:
Detects up to 30 human targets simultaneously; Supports up to 4 shield regions.
People Counting:
Supports entering/exiting counting (track 30 targets simultaneously); Supports facial recognition; Supports 24-hour dynamic deduplication and face library deduplication (up to 3 face libraries with up to 30000 faces); Supports reporting alarms when d
Queue Management:
Detects queuing-up people number, and waiting time of each person; Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue; Supports raw data export for further analysis.
Perimeter Protection:
Line crossing, intrusion, region entrance, region exiting;Support alarm triggering by specified target types (human and vehicle);Filtering out mistaken alarm caused by target types such as leaf, light, animal, and flag, etc.
Metadata:
Metadata of intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal, face capture and queue management are supported.
Power:
With extra load: 12 VDC ± 20%, 1.16 A, max. 13.9 W; PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.33 A to 0.25 A, class 4; Without extra load: 12 VDC ± 20%, max. 12.5 W; PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.3 A to 0.22 A, cla
Language:
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Tradition
Heater:
Yes
General Function:
Anti- flicker, 5 streams and up to 5 custom streams, EPTZ, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter
Storage Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions:
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Material:
Aluminum alloy body
Dimension:
Ø162 mm × 141.8 mm (Ø6.4" × 5.6")
Package Dimension:
251 mm × 215 mm × 189 mm (9.9" × 8.5" × 7.4")
Weight:
Without -Y: approx. 1480 g (3.3 lb.);With -Y: approx. 1550 g (3.4 lb.)
With Package Weight:
Without -Y: approx. 2407 g (5.3 lb.);With -Y: approx. 2206 g (4.9 lb.)
EMC:
FCC (47 CFR Part 15, Subpart B);CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);RCM (AS/NZS CISPR 32: 2015);IC (ICES-003: Issue 6, 2016);KC (KN 32: 2015, KN 35: 2015)
Safety:
UL (UL 60950-1);CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013);CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013);LOA (IEC/EN 60950-1);BIS (IS 13252(Part 1): 2010+A1: 2013+A2: 2015)
Environment:
CE-RoHS (2011/65/EU);WEEE (2012/19/EU);Reach (Regulation (EC) No 1907/2006)
Protection:
IP67 (IEC 60529-2013);IK10 (IEC 62262: 2002)
Automotive And Railway:
With -R: EN50121-4
Anti-Corrosion Protection:
With -Y: NEMA 4X (NEMA 250-2018)
Other:
With -Y: PVC FREE
EMC:
FCC (47 CFR Part 15, Subpart B)CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014)RCM (AS/NZS CISPR 32: 2015)IC (ICES-003: Issue 6, 2016)KC (KN 32: 2015, KN 35: 2015)
Safety:
UL (UL 60950-1)CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013)CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013)LOA (IEC/EN 60950-1)BIS (IS 13252(Part 1): 2010+A1: 2013+A2: 2015)
Environment:
CE-RoHS (2011/65/EU)WEEE (2012/19/EU)Reach (Regulation (EC) No 1907/2006)
Protection:
IP67 (IEC 60529-2013)IK10 (IEC 62262: 2002)
