Image Sensor:
Approx. 1/2.8 type CMOS image sensor
Minimum Illumination:
Color : 0.007 lx (30IRE, F1.3, 1/30s), Color : 0.009 lx (50IRE, F1.3, 1/30s); BW : 0.005 lx (50IRE, F1.3, 1/30s), BW : 0 lx (50IRE, F1.3,1/30s with IR LED)
White Balance:
ATW1 / ATW2 / AWC
Shutter Speed:
[60 fps Mode] 1/60 Fix to 1/10000 Fix, [30 fps/15 fps mode] 1/30 Fix to 1/10000 Fix; [50 fps Mode] 1/50 Fix to 1/10000 Fix, [25 fps/12.5 fps mode] 1/25 Fix to 1/10000 Fix
Intelligent Auto:
On / Off
Super Dynamic*2:
On / Off,; The level can be set in the range of 0 to 31.
Dynamic Range:
Max.144 dB; (Super Dynamic : On, Level 31)
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back light compensation / High light compensation:
BLC (Back light compensation) / HLC (High light compensation) /; Off (only when Super dynamic / Intelligent Auto : Off)
Fog Compensation:
On / Off (only when Intelligent auto / auto contrast adjust : Off)
Maximum Gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) /Auto2 (IR Light On) / Auto3 (SCC)
IR LED Light:
High / Middle / Low / Off,; Maximum irradiation distance : 70 m {Approx. 230 ft} (30IRE), 50 m {Approx. 164 ft} (50IRE)
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Video Motion Detection (VMD:
On / Off, 4 areas available
Scene Change Detection (SCD:
On / Off, 1 areas available
Audio Detection:
On / Off
AI Sound classification:
Gunshot, Yell, Vehicle horn, Glass break
AI Analytics:
Yes
Privacy Zone:
On / Off, Up to 8 zones available
VIQS:
On / Off, Up to 8 zones available
Image rotation*3:
0 ° / 90 ° / 180 ° / 270 °
Camera Title (OSD:
On / Off,; Up to 40 characters (alphanumeric characters, marks)
Focus Adjustment:
Auto focus
Optical Zoom:
3.1x (Motorized zoom / Motorized Focus)
Extra zoom:
3.1x - 9.3x (when resolution is 640 x 360)
Focal Length:
2.9 - 9 mm {1/8 inches - 11/32 inches}
Angular Field of View:
[16 : 9 mode] Horizontal : 36° (TELE) – 113° (WIDE), Vertical : 20° (TELE) – 60° (WIDE); [ 4 : 3 mode] Horizontal : 26° (TELE) – 82° (WIDE), Vertical : 20° (TELE) – 60° (WIDE)
Maximum Aperture Ratio:
1 : 1.3 (WIDE) – 1 : 2.5 (TELE)
Focusing Range:
0.3 m {11-13/16 inches} – ∞
Detect (25ppm / 8ppf:
Wide: 25.4m / 83.4 ft, Tele: 118.2 m / 387.7 ft
Observe (62.5ppm / 19ppf:
Wide: 10.2 m / 33.4 ft, Tele: 47.3 m / 155.1 ft
Recognize (125ppm / 38ppf:
Wide: 5.1 m / 16.7 ft, Tele: 23.6 m / 77.5 ft
Identify (250ppm / 76ppf:
Wide: 2.5m / 8.3 ft, Tele: 11.8 m / 38.8 ft
Adjusting Angle:
Horizontal : -194 to +166°, Vertical : -30 to +85°, Yaw : ±100°
Camera Control:
Brightness, AUX On / Off
Audio:
Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High; Audio Output : On / Off Volume adjustment : Low / Middle / High
GUI / Setup Menu Language:
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese
Browser*4:
Microsoft Edge, Firefox, Google Chrome
Network IF:
10Base-T / 100Base-TX, RJ45 connector
Resolution H.265/ H.264/ JPEG (MJPEG:
[16 : 9 mode (60 fps mode)], [16 : 9 mode (30 fps mode)],; [16 : 9 mode (50 fps mode)], [16 : 9 mode (25 fps mode)]; 1920x1080, 1280x720, 640x360, 320x180; [4 : 3 mode (30 fps mode)], [4 : 3 mode (25 fps mode)]; 1280x960, VGA, QVGA; [4 : 3 mode (15 f
JPEG - Image Quality:
10 steps
Smart Coding:
GOP (Group of pictures control):; Off/ Low (Variable GOP 1s-8s)/ Mid (Variable GOP 4s-16s)/; Advanced(Fixed GOP 60s w/1s key-frame)/; Frame rate control (Variable GOP 4s-16s with frame rate control); *Advanced and Frame rate control are only availabl
Audio Compression:
G.726 (ADPCM) : 16 kbps / 32 kbps, G.711 : 64 kbps; AAC-LC : 64 kbps / 96 kbps / 128 kbps
Audio Transmission Mode:
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex)
Supported Protocol:
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE,802.1X,DiffServ, LLDP; IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP
No. of Simultaneous Users:
Up to 14 users (Depends on network conditions)
Secure:
Device Certificate GlobalSign® pre-installed, User authentication,Host authentication, HTTPS, 802.1X Support, Data encryption
SDXC/SDHC/SD Memory Card (Option:
H.265 / H.264 recording :; Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure; JPEG recording :; Manual REC / Alarm REC (Pre/Post) / Backup upon network failure; Available SDXC/SDHC/SD Memory Card :; microSDXC memory card
Mobile Terminal Compatibility:
iPad, iPhone, Android™ terminals
ONVIF Profile:
G / S / T / M
Alarm Source:
3 terminals input, VMD alarm, Command alarm, Audio detection alarm
Alarm Actions:
SDXC/SDHC/SD memory recording, E-mail notification,; HTTP alarm notification Indication on browser, TCP alarm notification output
Monitor Output (for Adjustment:
VBS : 1.0 V [p-p] / 75 Ω, composite, Pin jack; An NTSC or PAL signal can be outputted from camera
Audio input*8:
ø3.5 mm stereo mini jack
Audio Output*8:
ø3.5 mm stereo mini jack (monaural output); Output impedance : Approx. 600 Ω (unbalanced), Output level : –20 dBV
External I/O Terminals*8:
ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1); ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1), ALARM IN 3 (Alarm input 3/ AUX OUT) (x1)
Safety:
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1
EMC:
FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassB, EN55035
Power Source and Power Consumption:
DC power supply*8 : DC12 V 730 mA, Approx. 8.8 W; PoE (IEEE802.3af compliant) Device : DC48 V 190 mA, Approx. 9.1 W (Class 0 device)
Ambient Operating Temperature:
-40 °C to +60 °C (-40 °F to 140 °F); (Power On range : –30 °C to +60 °C {–22 °F to +140 °F})
Ambient Operating Humidity:
10 to 100 % (no condensation)
Anti-Condensation System:
Temish element + Heater + moisture absorption gel
Water and Dust Resistance:
IP66, IEC60529 measuring standard compatible, Type 4X(UL50E), NEMA 4X compliant
Shock Resistance:
50J (IEC 60068-2-75 compliant), IK10 (IEC 62262)
Dimensions:
ø154 mm x 105 mm (H) {ø6-1/16 inches x 4-1/8 inches (H)}
Mass (Approx:
Approx. 1.1 kg {2.43 lbs.}
Finish:
Main body : Aluminum die cast and resin, i-PRO white; Outer fixing screws : Stainless steel (Corrosion-resistant treatment); Dome section : Polycarbonate resin, Clear (with ClearSight coating)
