Image Sensor:
3x 1/2.7 type CMOS image sensor
Scanning Area:
5.38 mm(H) x 3.02 mm(V); {7/32 inches(H) × 1/8 inches(V)}
Minimum Illumination:
Color : 0.21 lx {30IRE, F2.0, 1/30 s}; Color : 0.3 lx {50IRE, F2.0, 1/30 s}; BW : 0.12 lx {50IRE, F2.0, 1/30 s}; BW: 0 lx {50IRE, F2.0, 1/30 s with IR LED}
White Balance:
ATW1/ ATW2/ AWC
Maximum shutter:
30 fps mode: Max.1/10000s to Max.16/30s; 25 fps mode: Max.1/10000s to Max.16/25s
Intelligent Auto:
On / Off
Super Dynamic:
On / Off, The level can be set in the range of 0 to 31.
Dynamic Range:
Max. 108 dB(Super Dynamic: On, Level: 31)
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back Light Compensation/High Light Compensation:
BLC (Back light compensation) / HLC (High light compensation) /; Off (only when Super dynamic / Intelligent Auto : Off)
Fog Compensation:
On / Off (only when Intelligent auto / auto contrast adjust : Off)
Maximum Gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Off / On(IR Light Off) / On(IR Light On) / Auto1(IR Light Off) /; Auto2(IR Light On) / Auto3(SCC)
IR LED Light:
High / Middle / Low / Off; Maximum irradiation distance : 20 m {Approx. 66 ft} (30IRE); 15 m {Approx. 49 ft} (50IRE)
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Panorama:
Panorama mode (H: 170 deg.)
Video Motion Detection (VMD:
On / Off, 4 areas available
Scene Change Detection (SCD:
On / Off, 1 areas available
Audio Detection:
On / Off
AI Sound Classification:
Selectable from Gunshot, Yell, Vehicle horn, Glass break
AI Analytics:
AI Video Motion Detection, AI Privacy Guard, AI Face Detection,; AI People Detection, AI Vehicle Detection,; AI Non mask Detection, AI Occupancy Detection, AI Scene Change Detection; ; For details :; https://i-pro.com/products_and_solutions/en/survei
Privacy Zone:
On / Off,; Up to 8 zones available
VIQS:
On / Off,; Up to 8 zones available
Image Rotation:
0° (Off)/ 90°/ 180° (Upside-down)/ 270°
Camera Title (OSD:
On / Off, Up to 40 characters, Up to 2 Lines (alphanumeric characters, marks)
Focus Adjustment:
Auto focus
Optical zoom:
2.5x (Motorized zoom / Motorized focus)
Extra zoom:
max 10.5x (2.5x – 10.5x when resolution is 640x360)
Focal length:
2.9 mm {1/8 inches} – 7.3 mm {1/4 inches}
Angular Field of View:
Horizontal: 43°(TELE) - 100°(WIDE), Vertical: 24°(TELE) - 56°(WIDE)
Maximum Aperture Ratio:
1 : 2.0(WIDE) – 1 : 3.0(TELE)
Focus range:
1 m {3.28 ft} – ∞
Detect (25ppm / 8ppf:
Wide : 45.1 m / 148.0 ft, Tele : 136.5 m / 447.8 ft
Observe (62.5ppm / 19ppf:
Wide : 18.0 m / 59.2 ft, Tele : 54.6 m / 179.1 ft
Recognize (125ppm / 38ppf:
Wide : 9.0 m / 29.6 ft, Tele : 27.3 m / 89.6 ft
Identify (250ppm / 76ppf:
Wide : 4.5 m / 14.8 ft, Tele : 13.6 m / 44.8 ft
System on Chip (SoC:
Ambarella CV2
Adjusting Angle:
Camera 1, 2, 3 :; Horizontal : ±125° (Adjust by horizontal (PAN) angle); Vertical : +10° to +105° (Adjust by vertical (TILT) angle); Yaw : ±90° (Adjust by azimuth (YAW) angle); Twist : ±30°; *The above is the adjustable range of a single camera.; The
Camera Control:
Brightness, AUX On / Off
Audio:
Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High; Audio Output : On / Off Volume adjustment : Low / Middle / High
GUI / Setup Menu Language:
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese
Browser:
Microsoft Edge, Firefox, Google Chrome
Network IF:
10Base-T / 100Base-TX / 1000Base-T, RJ45 connector
Resolution H.265/ H.264/ JPEG (MJPEG:
[16 : 9 mode]; 2688 x 1520 / 2560 x 1440 / 1920×1080 /1280 x 720 / 640×360 / 320×180
H.265/H.264:
[Transmission Mode]; Constant bit rate / VBR / Frame rate / Best effort; [Transmission Type]; Unicast port (AUTO) / Unicast port (MANUAL) / Multicast
JPEG:
[Image Quality]; 10 steps
Smart Coding:
GOP (Group of pictures) control :; On (Frame rate control)* / On (Advanced)* / On (Mid) / On (Low) / Off; *On (Frame rate control) and On (Advanced) are only available with H.265.; Smart VIQS: On(High)/On(Low)/Off, Smart P-picture control: On/Off
Audio Compression:
G.726 (ADPCM) : 16 kbps / 32 kbps; G.711 : 64 kbps; AAC-LC : 64 kbps / 96 kbps / 128 kbps
Audio Transmission Mode:
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex)
Supported Protocol:
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3,; DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, LLDP, MQTT; IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS,; NTP, SNMPv1/v2/v3, U
No. of Simultaneous Users:
Up to 24 users; (Depends on network conditions)
Secure:
FIPS 140-2 level 3 Certified Secure Element (NXP® EdgeLock® SE050F), Device Certificate GlobalSign® pre-installed,; User authentication, Host authentication, HTTPS, 802.1X Support, Data encryption
SDXC/SDHC/SD Memory Card:
H.265 / H.264 recording :; Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure; JPEG recording :; Manual REC / Alarm REC (Pre/Post) / Backup upon network failure; Compatible SDXC/SDHC/SD Memory Card :; microSDXC memory card
Mobile Terminal Compatibility:
iPad, iPhone,; Android™ terminals
ONVIF® Profile:
G / M / S / T
Alarm Source:
3 terminals input, VMD alarm, SCD alarm, Command alarm, Audio detection alarm
Alarm Actions:
SDXC/SDHC/SD memory recording, E-mail notification,; HTTP alarm notification Indication on browser, TCP alarm notification output
Monitor Output (for Adjustment:
—
Audio input:
ø3.5 mm stereo mini jack; ; For microphone input : Recommended applicable microphone : Plug-in power type; (Sensitivity of microphone : -48 dB±3 dB (0 dB=1 V/Pa, 1 kHz)); Input impedance : Approx. 2 kΩ (unbalanced); Supply voltage : 2.4 V ±0.5 V; ; F
Audio Output:
ø3.5 mm stereo mini jack (monaural output); Output impedance : Approx. 600 Ω (unbalanced); Output level : –20 dBV
External I/O Terminals:
ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1); ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1), ALARM IN 3 (Alarm input 3/ ALARM OUT/ AUX OUT) (x1)
Safety:
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1
EMC:
FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassA, EN55035
Power Source and Power Consumption:
PoE+ (IEEE802.3at compliant):; DC 54 V: 470 mA/Approx. 25.4 W (Class 4 device)
Ambient Operating Temperature:
–40 °C to +60 °C*7 {–40 °F to 140 °F}; (Power On range: –20 °C to +60 °C {–4 °F to 140 °F}); Maximum temperature according to NEMA TS 2 (2.2.7): 74 °C(165 °F)
Ambient Operating Humidity:
10 to 100 % (no condensation)
Anti-Condensation System:
Temish element + Heater + moisture absorption gel
Water and Dust Resistance:
IP67/IP66 (IEC 60529), Type 4X (UL50E), NEMA 4X compliant
Shock Resistance:
IK10 (IEC 62262)
Wind Resistance:
Up to 40 m/s {approx. 89 mph}
Other standard support:
NEMA TS 2 (2.2.7-2.2.9)
Dimensions:
When using the attachment plate only :; ø300 mm × 90 mm (H) {ø11-13/16 inches ×3-17/32 inches (H)}
Mass (approx:
When using the attachment plate only : Approx. 3.1 kg {6.83 lbs}
Finish:
Main body : Aluminum die cast, i-PRO white; Outer fixing screws : Stainless steel (Corrosion-resistant treatment); Dome cover : PC resin, Clear
