Image Sensor:
Approx. 1/2.8 type CMOS image sensor
Scanning Area:
5.57 mm (H) × 3.13 mm (V)
Minimum Illumination:
Color : 0.13 lx (30IRE, F1.8, 1/30s) Color : 0.19 lx (50IRE, F1.8, 1/30s) BW : 0.1 lx (50IRE, F1.8, 1/30s)
White Balance:
ATW1 / ATW2 / AWC
Shutter Speed:
[30 fps mode] 1/30 Fix to 1/10000 Fix [25 fps mode] 1/25 Fix to 1/10000 Fix
Maximum shutter:
[30 fps Mode] Max.1/4000s to Max.16/30s [25 fps Mode] Max.1/4000s to Max.16/25s
Intelligent Auto:
On / Off
Super Dynamic:
On / Off, The level can be set in the range of 0 to 31.
Dynamic Range:
Max.132 dB
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back Light Compensation/ High Light Compensation:
BLC (Back light compensation) / HLC (High light compensation) / Off The level can be set in the range of 0 to 31 (only when Super dynamic / Intelligent Auto : Off)
Fog Compensation:
On / Off, The level can be set in the range of 0 to 8
Maximum Gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) / Auto2 (IR Light On) / Auto3 (SCC)
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Video Motion Detection (VMD:
On / Off, 4 areas available
Scene Change Detection (SCD:
On / Off, 1 areas available
Audio Detection:
On / Off
AI Sound Classification:
Gunshot, Yell, Vehicle horn, Glass break
AI Analytics:
AI Video Motion Detection, AI Privacy Guard, AI Face Detection, AI People Detection, AI Vehicle Detection, AI Non mask Detection, AI Occupancy Detection, AI Scene Change Detection
Privacy Zone:
On / Off, Up to 32 zones available
VIQS:
On / Off, Up to 8 zones available
Image Stabilizer:
On / Off (Built-in gyro sensor)
Image Rotation:
On / Off
Camera Title (OSD:
On / Off, Up to 40 characters (alphanumeric characters, marks)
Optical zoom:
30x (Motorized zoom / Motorized focus)
Extra zoom:
Max. 90x (30x - 90x when resolution is 1280x720)
Focal length:
4.5mm - 135mm (3/16 inches - 5-5/16 inches)
Angular Field of View:
[16 : 9 mode] Horizontal : 2.5° (TELE) – 62° (WIDE), Vertical : 1.4° (TELE) – 37° (WIDE)
Maximum Aperture Ratio:
1 : 1.8 (WIDE) – 1 : 4.7 (TELE)
Focus range:
3.0 m {118-1/8 inches} –∞
Aperture range:
F1.8 – close
DORI Detect (25ppm / 8ppf:
Wide: 127.8 m / 419.3 ft, Tele: 3519.7 m / 11547.6 ft
DORI Observe (62.5ppm / 19ppf:
Wide: 51.1 m / 167.7 ft, Tele: 1407.9 m / 4619.0 ft
DORI Recognize (125ppm / 38ppf:
Wide: 25.6 m / 83.9 ft, Tele: 703.9 m / 2309.5 ft
DORI Identify (250ppm / 76ppf:
Wide: 12.8 m / 41.9 ft, Tele: 352.0 m / 1154.8 ft
System on Chip (SoC:
Ambarella CV22
Adjusting Angle:
Horizontal : 360° Endless Panning, TILT : -20° to +90°, Yaw : 0°
Panning Range:
360° Endless panning
Panning Speed:
Manual: Approx. 0.065°/s – 150°/s Preset: Up to approx. 700°/s
Tilting Range:
Operational range -20° – +90°
Tilting Speed:
Manual: Approx. 0.065°/s –150°/s Preset: Up to approx. 500°/s
Preset Positions:
256 positions
Auto Mode:
Auto track/ Auto pan/ Preset sequence/ Patrol
Self Return:
10 s/ 20 s/ 30 s/ 1 min/ 2 min/ 3 min/ 5 min/ 10 min/ 20 min/ 30 min/ 60 min
Active ClearSight:
Yes
GUI / Setup Menu Language:
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese
Browser:
Microsoft Edge, Firefox, Google Chrome
Network IF:
10Base-T / 100Base-TX, RJ45 connector
Resolution H.265/ H.264/ JPEG (MJPEG:
[16:9 mode (30 fps mode) ] [16:9 mode (25 fps mode) ] 3840x2160/ 2560x1440/ 1920x1080/ 1280x720/ 640x360/ 320x180
H.265/H.264 Transmission Mode / Type:
[Transmission Mode] Constant bit rate / VBR / Frame rate / Best effort [Transmission Type] Unicast port (AUTO) / Unicast port (MANUAL) / Multicast
JPEG:
[Image Quality] 10 steps
Audio compression method:
G.726 (ADPCM) : 16 kbps / 32 kbps G.711 : 64 kbps AAC-LC : 64 kbps / 96 kbps / 128 kbps
Audio Transmission Mode:
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex)
Supported IPv6 Protocols:
TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ
Supported IPv4 Protocols:
TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ, SRTP, MQTT, NTCIP
No. of Simultaneous Users:
Up to 14 users (Depends on network conditions)
SDXC/SDHC:
H.265 / H.264 recording : Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure JPEG recording : Manual REC / Alarm REC (Pre/Post) / Backup upon network failure
SD Memory Card:
microSDXC memory card : 64 GB, 128 GB, 256 GB, 512 GB microSDHC memory card : 4 GB, 8 GB, 16 GB, 32 GB microSD memory card : 2 GB
Mobile Terminal Compatibility:
iPad, iPhone (iOS 8.0 or later), AndroidTM terminals
ONVIF®Profile:
G / M / S / T
Alarm Source:
3 terminals input, VMD alarm, Command alarm, Audio detection alarm
Alarm Actions:
SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification Indication on browser, TCP alarm notification output
Audio Input:
ø3.5 mm stereo mini jack
Audio Output:
ø3.5 mm stereo mini jack (Audio output is monaural.)
External I/O Terminals:
ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1) ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1), ALARM IN 3 (Alarm input 3/ AUX OUT) (x1)
Safety:
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1
EMC:
FCC (Part15 ClassA), ICES-003 Issue 7 ClassA, EN55032 ClassA, EN55035
Other Standard:
NEMA-TS2
Power Source and Power Consumption:
PoE++ (IEEE802.3bt compliant) DC 54 V : 700 mA/Approx. 37.8 W (Class 6 device)
Ambient Operating Temperature:
–50 °C to 60 °C * {–58 °F to 140 °F} (Power On range: –30 °C to +60 °C {–22 °F to 140 °F}) Maximum temperature according to NEMA TS 2 (2.2.7) : 74℃(165℉)
Ambient Operating Humidity:
10 to 100 % (no condensation)
Water and Dust Resistance:
IP66, IEC60529 measuring standard compatible, Type 4X(UL50E), NEMA 4X compliant
Shock Resistance:
IK10
Wind Resistance:
Up to 40 m/s {approx. 89 mph}
Dimensions:
Maximum diameter:φ167mm × 205 mm (H){φ6-9/16 inches × 8-1/16 inches (H)} Dome radius SR 77.5 mm {SR 3-1/16 inches}
Mass (approx:
Approx. 3 kg (without attachment)
Finish:
Main body : Aluminum die cast (Heavy-salt damage resistance coating), i-PRO white Outer fixing screws : Stainless steel (Corrosion-resistant treatment) Dome cover: Polycarbonate resin, Clear
Other:
Tamper-resistant enclosure
