Image Sensor:
4x 1/2.7 type CMOS image sensor; 1/2.8 type CMOS image sensor
Scanning Area:
5.12 mm (H) × 3.84 mm (V); {3/16 inches (H) × 5/32 inches (V)}; 5.57 mm (H) × 3.13 mm (V) {7/32 inches (H) × 1/8 inches (V)}
Minimum Illumination:
; Color : 0.12 lx (30IRE, F2.0, 1/30 s); Color : 0.17 lx (50IRE, F2.0, 1/30 s); BW : 0.10 lx (50IRE,F2.0, 1/30 s); ; Color : 0.011 lx (30IRE, F1.6, 1/30 s); Color : 0.015 lx (50IRE, F1.6, 1/30 s); BW : 0.006 lx (50IRE,F1.6, 1/30 s)
White Balance:
ATW1/ ATW2/ AWC
Maximum shutter:
; 15 fps mode: Max.1/10000s to Max.16/30s; ; 60 fps mode: Max.1/4000s to Max.16/30s; 30 fps mode: Max.1/4000s to Max.16/30s; 15 fps mode: Max.1/4000s to Max.16/30s
Intelligent Auto:
On / Off
Super Dynamic:
On / Off, The level can be set in the range of 0 to 31.; On / Off, The level can be set in the range of 0 to 31.*1
Dynamic Range:
108 dB max.(Super Dynamic: On, Level: 31); 144 dB max.(Super Dynamic: On, Level: 31)
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back Light Compensation/High Light Compensation:
BLC (Back light compensation) / HLC (High light compensation) / Off (only when Super dynamic / Intelligent Auto : Off)
Fog Compensation:
On / Off (only when Intelligent auto / auto contrast adjust : Off)
Maximum Gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Off/On/Auto1(Normal)/Auto2(IR Light)/Auto3(SCC)
IR LED Light:
-
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Panorama:
-
Video Motion Detection (VMD:
On / Off,; 4 areas available
Scene Change Detection (SCD:
On / Off,; 1 areas available
Audio Detection:
On/Off
AI Sound Classification:
Selectable from Gunshot, Yell, Vehicle horn, Glass break
AI Analytics:
AI Video Motion Detection, AI Privacy Guard, AI Face Detection, AI People Detection, AI Vehicle Detection, AI Non mask Detection, AI Occupancy Detection, AI Scene Change Detection; For details :; https://i-pro.com/products_and_solutions/en/surveillan
Privacy Zone:
On / Off, Up to 8 zones available; On / Off, Up to 32 zones available
VIQS:
On / Off, Up to 8 zones available; On / Off, Up to 8 zones available
Image Stabilizer:
-; On / Off (Built-in gyro sensor)
Image Rotation:
Upside-down: On/Off
Camera Title (OSD:
On/ Off,; Up to 40 characters, Up to 2 Lines (alphanumeric characters, marks)
Focus Adjustment:
-; Auto focus
Optical zoom:
1x; 21x (Motorized zoom / Motorized focus)
Extra zoom:
max 4.0x (when resolution is 640x360); max 31x (when resolution is 1280x720)
Focal length:
3.2mm; 4.0mm - 84.6mm{5/32inches - 3-11/32 inches}
Angular Field of View:
Horizontal : 97 deg. / Vertical : 71 deg.; Horizontal : 3.7 ° to 77 ° / Vertical : 2.2 ° to 44°
Maximum Aperture Ratio:
2; 1:1.6(WIDE) to 1:4.5(TELE)
Focus range:
1 m {3.28 ft} to ∞; 1.5 m {59-1/16 inches} to ∞
Detect (25ppm / 8ppf:
45.3 m / 148.6 ft; Wide: 48.3 m / 158.4 ft, Tele: 1188.9 m / 3900.5 ft
Observe (62.5ppm / 19ppf:
18.1 m / 59.4 ft; Wide: 19.3 m / 63.4 ft, Tele:475.5 m / 1560.2 ft
Recognize (125ppm / 38ppf:
9.1 m / 29.7 ft; Wide: 9.7 m / 31.7 ft, Tele: 237.8 m / 780.1 ft
Identify (250ppm / 76ppf:
4.5 m / 14.9 ft; Wide: 4.8 m / 15.8 ft, Tele: 118.9 m / 390.0 ft
System on Chip (SoC:
Ambarella CV2; Ambarella CV25m
Adjusting Angle:
Camera 1,2,3,4:Vertical: 40 ±7° (Adjust by vertical (TILT) angle); Horizontal : 360° Endless Panning / Vertical : -15 to +195°/Yaw : 0°
Panning Range:
360 °Endless panning
Panning Speed:
Manual : 0.065 °/s – 150°/s, Preset : Up to 500 °/s
Tilting Range:
Operational -15 – +195°
Tilting Speed:
Manual : 0.065 °/s – 150°/s, Preset : Up to 500 °/s
Preset Positions:
256 positions
Auto Mode:
Auto track / Auto pan/; Preset sequence/ Patrol
Self Return:
10 s/ 20 s/ 30 s/; 1 min/ 2 min/ 3 min/ 5 min/ 10 min/ 20 min/ 30 min/ 60 min
Camera Control:
Brightness, AUX On / Off
Audio:
Mic (Line) Input : On / Off, Volume adjustment : Low / Middle / High; Audio Output : On / Off, Volume adjustment : Low / Middle / High
GUI / Setup Menu Language:
English, Italian, French, German, Spanish, Portuguese,; Russian, Chinese, Japanese
Browser:
Microsoft Edge, Firefox, Google Chrome
Network IF:
10 BASE-T/100 BASE-T/1000 BASE-T,; RJ45 connector *2
Resolution H.265/ H.264/ JPEG (MJPEG:
; [4:3] (15fps mode)/[4:3] (12.5fps mode); 3072 x 2304*3, 2560x1920, 1280 x 960, VGA, QVGA; [4:3] (15fps Quad mode)/[4:3] (12.5fps Quad mode); 3072 x 2304*3, 2560x1920, 1280 x 960, VGA; [16:9] (15fps mode) / [16:9] (12.5fps mode); 3072 x 1728*3, 2560
H.265/H.264:
[Transmission Mode] Constant bit rate / VBR / Frame rate / Best effort; [Transmission Type] Unicast port (AUTO) / Unicast port (MANUAL) / Multicast
JPEG:
[Image Quality] 10 steps
Smart Coding:
GOP (Group of pictures) control : On (Frame rate control)* / On (Advanced)* / On (Mid) / On (Low) / Off; *On (Frame rate control) and On (Advanced) are only available with H.265.; Smart VIQS: On(High)/On(Low)/Off, Smart P-picture control: On/Off
Audio Compression:
G.726(ADPCM): 32 kbps/16 kbps, G.711: 64 kbps, AAC-LC: 64kbps/96kbps/128kbps *4
Audio Transmission Mode:
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex)
Supported Protocol:
IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X *5, DiffServ, LLDP, MQTT
No. of Simultaneous Users:
24 (Number of sessions that can connect to cameras at the same time); * Depends on network conditions; 14 (Number of sessions that can connect to cameras at the same time); * Depends on network conditions
Secure:
FIPS 140-2 level 3 (NXP® EdgeLock® SE050F), Device Certificate GlobalSign® pre-installed, User authentication, Host authentication, HTTPS, 802.1X Support *5, Alteration Detection
SDXC/SDHC/SD Memory Card:
microSDXC memory card:64 GB, 128 GB, 256 GB, 512 GB; microSDHC memory card:4 GB, 8 GB, 16 GB, 32 GB, microSD memory card :2 GB
Mobile Terminal Compatibility:
iPad / iPhone (iOS 8.0 or later),; AndroidTM terminals
ONVIF® Profile:
G / M / S / T
Alarm Source:
3 terminals input, VMD alarm, SCD alarm, Command alarm, Audio detection alarm
Alarm Actions:
SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification Indication on browser, TCP alarm notification output
Monitor Output (for Adjustment:
-
Audio input *6:
ø3.5 mm stereo mini jack; For microphone input :; Recommended applicable microphone : Plug-in power type (Sensitivity of microphone : -51 dB~-38dB (0 dB=1 V/Pa, 1 kHz)); Input impedance : Approx. 2 kΩ (unbalanced); Supply voltage:2.5 V ±0.5 V; For li
Audio Output *6:
ø3.5 mm stereo mini jack (Audio output is monaural.); Output impedance: Approx. 600 Ω (unbalanced), Output level: –20 dBV
External I/O Terminals *6:
ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1); ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1), ALARM IN 3 (Alarm input 3/ AUX OUT) (x1)
Safety:
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1
EMC:
FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassA, EN55035
Power Source and Power Consumption:
PoE++(IEEE802.3bt compliant):; DC 54 V : 0.66A/Approx. 35.6 W (Class 5 device)
Ambient Operating Temperature:
–40 °C to +55 °C {–40 °F to 131 °F}; (Power On range: –20 °C to +55 °C {–4 °F to 131°F}); Maximum temperature according to NEMA TS 2 (2.2.7) : 74℃(165℉)
Ambient Operating Humidity:
10 % to 100 % (no condensation)
Anti-Condensation System:
Temish element
Water and Dust Resistance:
IP67/IP66 (IEC 60529),; Type 4X (UL50E),; NEMA 4X compliant
Shock Resistance:
IK10 (IEC 62262)
Wind Resistance:
Up to 40 m/s {approx. 89 mph}
Other standard support:
NEMA TS 2 (2.2.7-2.2.9)
Dimensions:
ø250 mm x 195 mm (H)
Mass (approx:
Approx. 3.8 kg
Finish:
Main body: Aluminum die cast, i-PRO white; Outer fixing screws: Stainless steel (Corrosion-resistant treatment); Dome cover: PC resin, Clear
