Auto Search VIVOTEK Device:
Up to 256 pcs
Surveillance Device Management List:
V
DHCP Server Function:
V
Easy Tag VLAN in Topology View:
V
VIVOTEK Device Name Edit:
V
VIVOTEK Device Account/Password Setting:
V
VIVOTEK Device Static IP Setting:
V
VIVOTEK Camera/Video Server Reboot/Restore Default:
V
VIVOTEK Device Re-direct Link:
V
VIVOTEK Device On/Off Line Status:
V
Discover ONVIF IP camera:
V
Topology View:
V
Floor View:
V
Google Map View:
V
VIVOTEK Camera/Video Server Configuration File Export/Import:
V
VIVOTEK Cameras/Video Server Configuration File Management:
V
Floor Image Management:
V
Export Surveillance Management Device List:
V
Security:
V
Trouble Shooting:
V
Traffic Monitoring:
V
10M/100M/1G RJ45 PoE Port:
8
100M/1G SFP Port:
4
Console Port:
1xRJ45
Switching Capacity:
24 Gbps
Forwarding Capacity:
17.856 Mpps
MAC Address:
8K
Jumbo Frames:
9600 Bytes
Number of PoE Out Ports:
8
Max. PoE Output Power/Per Port:
30W
802.3at/af Standard Compatible:
V
Over Current Protection:
V
Circuit Shorting Protection:
V
Total PoE Power Budget:
240W
Power Pin Assignment:
1/2(+), 3/6(-)
PoE PD Auto Detection:
V
IEEE802.1D (STP:
V
IEEE802.1w (RSTP:
V
IEEE802.1s (MSTP:
V
802.1Q Tag-based VLAN:
4096 VLAN IDs
Port-based VLAN:
V
MAC-based VLAN:
V
Management VLAN:
V
Q-in-Q (Double Tag:
V
Private VLAN Edge (PVE:
V
Voice VLAN:
V
GARP VLAN Registration Protocol (GVRP:
V
IEEE 802.3ad LACP:
Up to 4 ports in a group, Max. up to 6 groups
IGMP Snooping (v1/v2/v3:
V
Loop Detection:
V
IEEE 802.3x Flow Control:
V
IP Host Table:
V
IPv4/v6 Static Routing:
V
Static ARP:
V
DHCP Server:
V
Supports ITU-T G.8031 Ethernet Linear Protection Switching:
V
Supports ITU-T G.8032 Ethernet Ring Protection Switching:
V
Convergence Time within 20ms:
V
Total Number of Switch:
Up to 250 units
Hardware Queues:
8
Port Based:
V
802.1p VLAN Priority Based:
V
Differentiated Services (DiffServ:
V
Classification and Re-marking ACLs:
V
Ingress Policer:
V
Egress Shaping and Rate Control:
V
Per Port:
V
Strict Priority and Weighted Round-robin (WRR:
V
Queue Assignment Based on DSCP and Class of Service:
V
Port Security (MAC-based:
V
IEEE802.1x:
V
Supports up to 256 Entries:
V
Source and Destination MAC, VLAN ID or IP Address, Protocol, Port:
V
Differentiated Services Code Point (DSCP) / IP Precedence:
V
TCP/ UDP Source and Destination Ports:
V
802.1p Priority:
V
Ethernet Type:
V
Internet Control Message Protocol (ICMP) Packets:
V
TCP Flag:
V
IP Source Guard (IP-MAC-Port Binding:
V
Storm Control:
V
RADIUS Authentication (RFC2138:
V
DDoS Prevention:
V
Layer 3 Isolation (Allow/Disallow Routing between IP Subnets:
V
HTTPs and SSL (Secured Web:
V
SSH v1.5/v2.0 (Secured Telnet Session:
V
BPDU Guard:
V
STP Root Guard:
V
DHCP Snooping:
V
SNMP (v1, v2c, v3:
V
RMON (1, 2, 3 & 9 groups:
V
CLI (Command Line Interface:
V
Web GUI Interface:
V
Firmware Upgrade:
V
Dual Image:
V
Configuration Export/Import:
V
Support DHCP Server to Assign IP to DHCP Clients:
V
Syslog:
V
SNMP:
V
Web:
V
Telnet:
V
Port Mirroring:
V
Remote Monitoring (RMON:
V
LLDP (IEEE802.1ab:
V
LLDP-MED:
V
NTP:
V
UPnP:
V
S-Flow:
V
IEEE 1588v2 PTP:
V
Temperature Detection and Alarm:
V
Supported to Resume Operation from CPU Hang up:
V
Dual IPv6/IPv4 Stack:
V
IPv6 Web/SSL:
V
IPv6 SNTP (Simple Network Time Protocol:
V
IPv6 Telnet Server/SSH:
V
IPv6 Ping Trace Route:
V
IPv6 TFTP:
V
IPv6 RADIUS:
V
IPv6 Syslog:
V
IPv6 DNS Client:
V
IPv6 Protocol-based VLANs:
V
IPv6 SNMP:
V
ON/OFF Control:
V
Alive Checking for PD:
V
Power Delay:
V
7/24 On/Off Scheduling:
V
Operating Temperature:
-40°C ~ 75°C (-40°F ~ 167°F)
Storage Temperature:
-40°C ~ 85°C (-40°F ~ 185°F)
Operating Humidity:
5% ~ 90% Non-Condensing
Dimensions:
62(W) x 135(H) x 130(D) mm
Weight:
0.68 kg
Power Input Voltage:
PW1: 48 ~ 57VDC; PW2: 48 ~ 57VDC; Redundant Power Backup
Output Voltage Range /Per PoE Port:
54VDC; PoE IEEE 802.3af (Max. 15.4W) output; PoE+ IEEE802.3at (Max. 30W) output
Surge Protection /Per PoE Port:
6KV
Warranty:
60 months
EMS:
EN61000-4-2 ESD, EN61000-4-3 RS, EN61000-4-4 EFT, EN61000-4-5 Surge, EN61000-4-6 CS, EN61000-4-8 PFMF
EMI:
FCC Part 15 Class A
Safety:
CE, LVD, VCCI
Vibration:
IEC 60068-2-6
Shock:
IEC 60068-2-27
Freefall:
IEC 60068-2-32
