Vivotek HLG-120H-48 Power Supply 90-305VAC Input 48VDC/120W Output IP67 -40°C to 70°C

$129.60

Add to Cart for Sale Price!

$84.99
Adding to cart… The item has been added
SKU: HLG-120H-48
Availability: Usually Ships Same Business Day

Industry Leading Prices

Quantity Discounts
Available

Certified Experts

Pre and Post-sales
Support Available

Free Shipping on Orders Over $499

Same Day Shipping on
Most Orders

Vivotek HLG-120H-48 Power Supply 90-305VAC Input 48VDC/120W Output IP67 -40°C to 70°C

$129.60

Add to Cart for Sale Price!

$84.99
Add to Cart
Description

The Vivotek HLG-120H-48 Power Supply is engineered to deliver exceptional performance and reliability in the most demanding IP surveillance environments. This power supply unit excels in indoor and outdoor applications and can convertange of 90-305VA a broad input rC into a precise 48VDC/120W output. Its IP67 certification ensures robust protection against dust and water immersion, and its ability to function in extreme temperatures from -40°C to 70°C makes it an ideal choice for critical installations where consistent operation is necessary.

Key Features:

  • High Power Output: Efficiently delivers 48VDC at 120W, capable of supporting multiple high-powered devices.
  • Wide Input Range: Adapts seamlessly to various power inputs ranging from 90-305VAC, suitable for global usage.
  • IP67 Rated: Offers complete protection against environmental elements, making it dustproof and waterproof.
  • Extreme Temperature Operation: Designed to work reliably in a temperature range of -40°C to 70°C, ideal for harsh conditions.
  • Built-In Protection Mechanisms: Features comprehensive safety protections, including overcurrent, overvoltage, and short-circuit prevention.

Compatibility:

  • Surveillance Equipment: Specifically designed to power Vivotek IP cameras and other compatible surveillance devices.
  • Industrial Applications: Suitable for industrial settings that demand high durability and reliable power supply.
  • Versatile Installations: Its robust features make it applicable for both indoor and outdoor installations, ensuring smooth operation in diverse environments.

Package Contents:

  • Vivotek HLG-120H-48 Power Supply
  • AC Power Cable
  • User Installation Guide

Summary:

The Vivotek HLG-120H-48 is a superior choice for powering sophisticated surveillance systems. With its high output, extreme environmental durability, and comprehensive safety features, this power supply ensures uninterrupted operation and long-lasting reliability, making it an invaluable component of any high-stakes security setup.

Specifications
DC VOLTAGE: 48V
CONSTANT CURRENT REGION: 24 ~ 48V
RATED CURRENT: 2.5A
RATED POWER: 120W
RIPPLE & NOISE (max: 200mVp-p
VOLTAGE ADJ. RANGE: 43 ~ 53V
CURRENT ADJ. RANGE: 1.2 ~ 2.5A
VOLTAGE TOLERANCE: ±1.0%
LINE REGULATION: ±0.5%
LOAD REGULATION: ±0.5%
SETUP, RISE TIME: 1200ms,50ms/115VAC 500ms,50ms/230VAC at full load ; B type 1200ms,200ms/115VAC 500ms,200ms/230VAC at 95% load
HOLD UP TIME (Typ: 12ms at full load 230VAC / 115VAC
VOLTAGE RANGE: 90 ~ 305VAC, 127 ~ 431VDC
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR (Typ: PF>0.98/115VAC, PF>0.95/230VAC, PF>0.93/277VAC at full load (Please refer to "Power Factor Characteristic" curve)
TOTAL HARMONIC DISTORTION: THD< 20% when output loading≧50% at 115VAC/230VAC input and output loading≧75% at 277VAC input
EFFICIENCY (Typ: 0.935
AC CURRENT (Typ: 0.6A / 230VAC
INRUSH CURRENT (Typ: COLD START 60A(twidth=375μs measured at 50% Ipeak) at 230VAC
MAX. No. of PSUs on 16A CIRCUIT BREAKER: 5 units (circuit breaker of type B) / 9 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT:
OVER CURRENT: 95 ~ 108% Protection type : Constant current limiting, recovers automatically after fault condition is removed
SHORT CIRCUIT: Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE: 54 ~ 63V Protection type : Shut down o/p voltage with auto-recovery or re-power on to recovery
OVER TEMPERATURE: Shut down o/p voltage, recovers automatically after temperature goes down
WORKING TEMP: -40 ~ +70℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 20 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY: -40 ~ +80℃, 10 ~ 95% RH
TEMP. COEFFICIENT: ±0.03%/℃ (0 ~ 50℃)
VIBRATION: 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes
SAFETY STANDARDS: UL8750, CSA C22.2 No. 250.0-08, ENEC, TUV EN61347-1, EN61347-2-13 independent IP65 or IP67, J61347-1, J61347-2-13 approved ; design refer to UL60950-1, TUV EN60950-1
WITHSTAND VOLTAGE: I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
ISOLATION RESISTANCE: I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION: Compliance to EN55015, EN55022 (CISPR22) Class B, EN61000-3-2 Class C (≧50% load) ; EN61000-3-3
EMC IMMUNITY: Compliance to EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024, light industry level (surge 4KV), criteria A
MTBF: 192.2K hrs min. MIL-HDBK-217F (25℃)
DIMENSION: 220*68*38.8mm (L*W*H)
PACKING: 1.12Kg; 12pcs/14.4Kg/0.8CUFT
