Model:
SD9384-EHL
CPU:
Multimedia SoC (System-on-Chip)
Flash:
8 GB
RAM:
2 GB
Image Sensor:
1/2.8" Progressive CMOS
Max. Resolution:
2560x1920 (5MP)
Lens Type:
30x Optical Zoom, Auto Focus
Focal Length:
f = 4.94 ~ 148.24 mm
Aperture:
F1.3 ~ F4.6
Iris Type:
DC-iris
Field of View:
54.1° ~ 1.9° (Horizontal); 41.2° ~ 1.4° (Vertical); 65.7° ~2.4° (Diagonal)
Shutter Time:
1 sec. to 1/100,000 sec.
WDR Technology:
WDR Pro
Day/Night:
Yes
Removable IR-cut Filter:
Yes
IR Illuminators:
Built-in IR Illuminators up to 200 meters with Smart IR, IR LED*8
Minimum Illumination:
0.03 lux @ F1.3 (Color); 0.005 lux @ F1.3 (B/W); 0 lux with IR illumination on
Pan Speed:
Preset speed: 450°/s
Pan Range:
360° endless
Tilt Speed:
Preset speed: 450°/s
Tilt Range:
-20° to 90° (auto flip)
Preset Locations:
256 preset locations; 128 presets per tour
Pan/Tilt/Zoom Functionalities:
32x digital zoom (4x on IE plug-in, 8x built in); Auto Pan mode; Auto Patrol mode; Mechanical Auto flip
Storage:
Seamless Recording to MicroSD/SDHC/SDXC card and recording to network-attached storage (NAS)
Built-in Installation Aids:
Remote focus, remote zoom
Video Compression:
H.265, H.264, MJPEG
Maximum Frame Rate:
30 fps @ 2560x1920; 30 fps @ 2560x1440; 60 fps @ 1920x1080
Maximum Streams:
3 video streams (Up to 8 configurable profiles)
S/N Ratio:
74 dB
Dynamic Range:
120 dB
Video Streaming:
Adjustable resolution, quality and constant bitrate control, Smart Stream III
Image Settings:
General settings: video title and time stamp overlay, video orientation (flip, mirror), day/night settings; Illuminators: illuminators, anti-overexposure; Image settings: white balance, image adjustment (brightness, contrast, saturation, sharpness, g
Audio Capability:
Two-way audio (Full duplex)
Audio Compression:
G.711, G.726
Audio Interface:
External line input; External line output
Users:
Live viewing for up to 10 clients
Security:
Access list, digest authentication, HTTPS , IEEE 802.1x, password protection, Secure boot, Signed firmware, Trend Micro IoT Security (brute force attack event, cyberattack event, quarantine event), User access log, User account management
Protocols:
802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP/SFTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTCIP, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2, UDP, UPnP
Interface:
Capable of connecting 10 Base-T/100 Base-TX/1000 Base TX(RJ-45) Ethernet cable; *It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
ONVIF:
Profile G, S, T supported, specification available at www.onvif.org
Compute Capability:
SoC with built-in hardware deep learning accelerator
Vision Object Analytics:
Object Detection: People, Vehicle (4-wheeled, 2-wheeled); Attribute Extraction: People (gender, clothing color, bag, hat), Vehicle (bike, bus, car, motorcycle, truck, color); Re-Search Extraction; Path Extraction
Application:
Deep Learning VCA (Smart Motion Detection, Smart Tracking Advanced); Smart Tracking Advanced (Intrusion detection, Loitering detection, Line crossing detection, Face detection, Unattended object detection, Missing object detection)
Video Motion Detection:
Motion Detection (Five-window video motion detection)
VADP Package:
Stratocast, Trend Micro IoT Security (3-year free trial)
Event Trigger:
Audio detection, camera tampering detection, cybersecurity events (brute force attack event, cyberattack event, quarantine event), digital input, manual trigger, motion detection, periodical trigger, recording notification, SD card life expectancy, s
Event Action:
Event notification via audio clip, camera link, digital output, email, HTTP, FTP, NAS server, SD card; File upload via email, HTTP, FTP, NAS server, SD card; trigger track, trigger patrol, move to preset
Connectors:
RJ-45 cable connector for 10/100 Mbps PoE network connection; Audio line input; Audio line output; DC 48V power input; AC 24V power input; Digital input*2; Digital output*1; RS-485*1
LED Indicator:
System power and status indicator
Power Input:
AC 24V, DC 48V, IEEE 802.3 bt Class 6 PoE; (Simultaneous Power Redundancy Supported)
Power Consumption:
PoE: Max. 51W/26W (IR on/off); DC 48V: Max. 51W/26W (IR on/off); AC 24V: Max. 51W/26W (IR on/off)
Dimensions:
256 x 336 mm
Weight:
7.1 kg
Certifications:
EMC: CE (EN 55032 Class A, EN55035, EN50121-4), UKCA (BS EN 55032: 2015 +Q71: 2020, BS EN 55035: 2017), FCC (FCC Part 15 Subpart B Class A), IC (ICES-003:2020 Issue7, Class A), RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A); Safety: UKCA
Operating Temperature:
Starting Temperature: -40°C ~ 55°C (-40°F ~ 131°F); Working Temperature: -40°C ~ 60°C (-40°F ~ 140°F) (IR on)
Humidity:
98% RH (non-condensing)
Operating System:
Microsoft Windows 10/8/7; Mac 10.12 (Chrome only)
Web Browser:
Chrome 58.0 or above; Internet Explorer 10/11
Other Players:
VLC: 1.1.11 or above
Packing Contents:
Wall mount bracket, Screw pack, Screws and anchors, T10 and T25 L-wrench, Waterproof round cap, Quick installation guide, Terminal blocks (for DI/DO audio, AC/DC/GND wires, RS485), Ground wire.
Detect (25PPM/ 8PPF:
Wide: 104.1 m (341.5 ft); Tele: 2969.8 m (9743.4 ft)
Observe (63PPM/ 19PPF:
Wide: 41.3 m (135.5 ft); Tele: 1178.5 m (3866.4 ft)
Recognize (125PPM/ 38PPF:
Wide: 20.8 m (68.2 ft); Tele: 594 m (1948.6 ft)
Identify (250PPM/ 76PPF:
Wide: 10.4 m (34.1 ft); Tele: 297 m (974.3 ft)
