Vivotek Vortex FD819 H (5MP) Outdoor WDR Pro Fixed Microphone IP Camera

Add to Cart for Sale Price!

$519.99

Vivotek Vortex FD819 H (5MP) Outdoor WDR Pro Fixed Microphone IP Camera

Add to Cart for Sale Price!

$519.99
Description

The Vivotek Vortex FD819 H is a state-of-the-art 5MP outdoor IP camera crafted for sophisticated surveillance that delivers high-definition imagery under various environmental conditions. This camera features WDR Pro technology, which enhances video quality in environments with contrasting light levels, ensuring detailed imaging even in backlit or shadowed areas. Its built-in microphone adds an extra dimension to surveillance by capturing clear audio, complementing the visual data for a comprehensive security setup. Ideal for deployment in areas such as parking lots, entranceways, and around perimeters, the Vivotek Vortex FD819 H is an essential tool for businesses seeking a robust and reliable outdoor surveillance solution.

This camera is housed in an IP66-rated enclosure, protecting it from dust, rain, and other environmental elements, ideally suited for outdoor use. The fixed lens offers a wide field of view, ensuring extensive coverage without mechanical adjustment. With H.265 compression technology, the Vivotek Vortex FD819 H optimizes network bandwidth and storage space, reducing the total cost of operation while maintaining high-quality video streams.

Key Features:

  • 5MP High-Resolution Camera: Captures images in full HD, providing crystal-clear video footage.
  • WDR Pro Technology: Adjusts to varying light conditions to deliver consistently high-quality images.
  • Built-In Microphone: Enhances security monitoring with audio recording capabilities.
  • IP66 Weatherproof Rating: Ensures reliable performance in adverse weather conditions.
  • Fixed Wide-Angle Lens: Offers comprehensive coverage ideal for wide-area surveillance.
  • H.265 Compression: Reduces bandwidth and storage requirements without compromising video quality.
  • Smart Stream III Technology: Further enhances compression for critical regions in the camera's view.
  • Night Vision: Equipped with IR illuminators to provide clear images even in complete darkness up to 30 meters.

Compatibility:

  • Compatible with Vivotek's NVR and VMS systems.
  • Supports ONVIF for integration with third-party network video devices.
  • Can be powered by PoE (Power over Ethernet) or direct current, facilitating easy installation.

Package Contents:

  • Vivotek Vortex FD819 H IP Camera
  • Mounting Bracket
  • Waterproof Connector
  • Quick Installation Guide
  • Alignment Sticker
  • Software DVD
  • Warranty Card

Summary: The Vivotek Vortex FD819 H excels in outdoor surveillance, combining 5MP high-resolution imaging, audio recording, and advanced video compression technologies. Its durable, weather-resistant design and superior image clarity make it an invaluable asset for businesses aiming to enhance their security infrastructure. This camera provides peace of mind with its comprehensive coverage and dependable performance, standing out as a top choice in the competitive field of IP surveillance.

Specifications
Image sensor: 1/2.7 Progressive CMOS
Resolution: SD: 1280 x 960, HD: 2560 x 1920
Lens Types: Fixed focal
Focal Length: f = 2.8 mm
Aperture: F2.0
Iris: Fixed iris
Field of View: 103° (Horizontal), 76° (Vertical), 134° (Diagonal)
Camera Movement: Pan 350° Tilt: 80° Rotate:±175°
Shutter Speed: 1/5 sec. to 1/32,000 sec.
Day/Night: Yes
IR Cut Filter: Yes
IR Range: 30 meters
Minimum Illumination: 0.06 lux @ F2.0 (Color), 0.01 lux @ F2.0 (B/W), 0 lux with IR illumination on
Onboard Storage: MicroSD/SDHC/SDXC card slot, (Built in 256GB industrial SDCard)
Frame Rate: 15FPS
Video Streaming Settings: HD Video 2560 x 1920@15fps 1.2Mbps upload, SD Video 1280 x 960@15fps 300Kbps upload
Audio: One way Audio
Interface: Built in microphone
Effective Range: 5 meters
Audio detection: Yes
Tampering detection: Yes
People Analytics: Intrusion detection, Line crossing detection, Loitering detection, Scene Search
Vehicle Analytics: Intrusion detection, Line crossing detection, Loitering detection, Scene Search
Object Analytics: Unattended object detection, Missing object detection
Power input: IEEE 802.3af PoE Class 0
Power Consumption: Max. 6.3 W (IR on), Max. 3.9 W (IR off)
Connectivity: RJ 45 cable connector for 10/100 Mbps PoE network connection
RTSP: WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, IPv6, NTP, QoS (CoS/DSCP), RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP
Users: Up to 6 clients, *Live viewing for 6 clients, *live viewing up to 4 clients and playback 2 clients)
Security: Secure boot, Signed firmware, HTTPS/TLS encryption, Video encryption
Interface: 10 Base T/100 Base TX Ethernet (RJ 45)
Operating Temperature: Starting Temperature: 0°C ~ 50°C (32°F ~ 122°F), Working Temperature:: 10°C ~ 50°C (14°F ~ 122°F) (IR off), 10°C ~ 45°C (14°F ~ 113°F) (IR on)
Humidity: 90% RH (non condensing)
Certifications: EMC: CE (EN55032, EN55024 Class B, E50121 4), FCC (FCC Part 15 Subpart B Class B), RCM (AS/NZS CISPR32 Class B), VCCI (VCCI CISPR 32 Class B); Safety : UL (UL62368 1), CB (IEC/EN 62368 1, IEC/EN 60950 22, IEC/EN 62471)
Warranty: 120 month
Included Accessories: Quick installation guide, alignment sticker, screw pack
Weight: 350g
Dimensions: Ø 130 x 95 mm
Body: Plastic
